ALUMINUM ELECTROLYTIC CAPACITORS
KZ
Premium Grade Type, For Audio Equipment
series
Premium grade “nichicon MUSE” acoustic series.
Ideally suited for first class audio equipment where qualitative and quantitative
comfortableness is required.
Compliant to the RoHS directive (2002/95/EC).
KZ
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
High Grade
FG
Performance Characteristics
– 40 to +85°C
25 to 100V
10 to 1000µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage, leakage current is 0.01CV or less.
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage (V)
tan
δ
(MAX.)
25
0.12
25
2
4
50
0.08
50
2
3
100
0.07
100
2
3
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Impedance ratio
Z– 25°C / Z+20°C
ZT / Z20 (MAX.)
Z– 40°C / Z+20°C
Endurance
Shelf Life
Marking
The specifications listed at right shall be met
Capacitance change
Within ±20% of the initial capacitance value
when the capacitors are restored to 20°C after
tan
δ
150% or less than the initial specified value
the rated voltage is applied for 1000 hours at
Less than or equal to the initial specified value
Leakage Current
85°C.
After storing the capacitors under no load at 85°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
Printed with gold color letter on black sleeve.
Radial Lead Type
Sleeve (P.E.T.)
φ
0.8 tinned copper wire
Type numbering system (Example : 25V 100
µ
F)
1
2
3
4
5
6
7
8
9 10
11
UK Z 1 E 1 0 1 M PM
φD
+
0.5MAX.
P
±
0.5
Configuration
Capacitance tolerance
(±20%)
Rated capacitance (100µF)
φD
8 · 10
12.5 to 18
Code
PM
HM
Pressure
relief vent
Rated voltage (25V)
L+
MAX.
15
MIN
4
MIN
(mm)
Series name
Type
α
(φ D < 10) 1.0
(φ D 10) 1.5
φD
P
8
3.5
10
5.0
12.5
5.0
16
7.5
18
7.5
•
Please refer to page 20 about the end seal configulation.
Dimensions
Cap.(µF)
V
Code
φ
D
×
L (mm)
25
1E
8
×
11.5
10
×
12.5
10
×
16
12.5
×
20
12.5
×
25
16
×
25
16
×
35.5
50
1H
8
×
11.5
10
×
12.5
10
×
16
12.5
×
20
16
×
25
16
×
31.5
16
×
35.5
18
×
40
100
2A
8
×
11.5
10
×
16
10
×
20
12.5
×
20
16
×
25
16
×
35.5
18
×
35.5
10
22
33
47
1000
2200
3300
4700
100000
100
220
330
470
101
221
331
471
102
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
