Wire Guard |
Spacing 7.5 mm
AK114/..DS-7.5-V-GREY
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.2 mm²
4.0 mm²
0.2 mm²
2.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 7.5 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
Width (mm)
15.70
23.20
30.70
38.20
45.70
53.20
60.70
68.20
75.70
83.20
90.70
Article Designation
AK114/2DS-7.5-V-GREY
AK114/3DS-7.5-V-GREY
AK114/4DS-7.5-V-GREY
AK114/5DS-7.5-V-GREY
AK114/6DS-7.5-V-GREY
AK114/7DS-7.5-V-GREY
AK114/8DS-7.5-V-GREY
AK114/9DS-7.5-V-GREY
AK114/10DS-7.5-V-GREY
AK114/11DS-7.5-V-GREY
AK114/12DS-7.5-V-GREY
Article Number
50114020070F
50114030070F
50114040070F
50114050070E
50114060070E
50114070070E
50114080070E
50114090070E
50114100070D
50114110070D
50114120070D
PU
200
200
200
100
100
100
100
100
50
50
50
Stranded with Ferrule 0.2 mm²
min
Stranded with Ferrule 2.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Clamp
Wire Guard
Screw
Brass
Stainless Steel
Steel
7.0 mm
2.0 mm x 2.8 mm
Accessories
Figure
Designation
Brücke, 2-polig, isoliert, BRI/2-7.5-7.62-
L8.2-LICHTGRAU
Article Number
50000000017
Colours
RAL7016
GREY , RAL7016
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
B
300 V
20 A
AWG 22-12
AWG 22-12
0.80 Nm
M3
1.6 kV
C
150 V
20 A
AWG 22-12
AWG 22-12
0.80 Nm
M3
1.6 kV
D
300 V
20 A
AWG 22-12
AWG 22-12
0.80 Nm
M3
1.6 kV
min
0.5 mm²
0.5 mm²
500 V
32 A
max
4.0 mm²
4.0 mm²
0.50 Nm
M3
3.0 kV
www.ptr.eu
