Metal Glaze Fixed Resistors
Type RGP Series
Key Features
I
The thick film is suitable
for the manufacture of
very high resistance
values and for high
voltage working
components.
The combination of high
values and high working
voltage makes these
components ideally
suited for such
applications as TVs,
electrical measuring
equipment etc..
Thick film metal glaze
series for high ohmic
values and high voltage
surge rating with a range
up to 10 Gohm.
Metal glaze resistors are manufactured using thick film techniques. The ceramic slugs
have the thick film applied, the film is fired and end caps are forced onto the slugs, the
resistive element is spiralled to value and lead wires are welded onto the end caps. Four
layers of coating are applied - the first being a phenolic resin, the other three being epoxy.
I
I
Characteristics - Electrical
RGP0207CH
Rated Power @ 70°C (W):
Resistance Range (ohms) Min:
Max:
Tolerance (%):
Code Letter:
Temp. Coefficient Max (ppm/°C):
Selection Series:
Limiting Element Voltage (V):
Maximum Overload Voltage (V):
Operating Temp. Range (°C):
Climatic Category:
Voltage Coefficient (±%/V):
Typical Noise at 47Mohm:
Dielectric Strength (V):
Insulation Resistance (Mohms):
750
1K0
1K0
1K5
1K5
2K5
0.25
1M0
1G0
RGP50
0.5
1M0
3G0
RGP100
1
1M0
5G0
5
J
10
K
E24
5K0
7K5
10K
15K
15K
20K
RGP200
2
1M0
5G0
RGP300
3
1M0
10G
RGP400
4
1M0
10G
±350
-55 to +155
55/155/56
0.005
0.75
300
1000
Dimensions
Style
RGP0207CH
RGP50
RGP100
RGP200
RGP300
RGP400
L±1
6.5
13.0
14.5
27.0
42.0
52.0
D ± 0.5
2.5
4.5
5.5
7.0
7.0
8.0
d ± 0.1
0.6
0.8
0.8
0.8
0.8
1.0
l±2
28
38
38
38
38
38
1773267 CIS BI 06/2011
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Metal Glaze Fixed Resistors
Type RGP Series
Derating Curve
100
Percent Rated Power
80
60
40
20
0
40
60 70 80
100
120
140
160
Ambient Temperature (°C)
Mounting
The resistors are suitable for processing on automatic insertion equipment and cutting and bending machines.
Marking
RGP0207CH are marked with a four band colour code in accordance with IEC 62. All others are marked
alpha-numerically with the type, value and tolerance.
Packaging
RGP0207CH resistors are normally supplied taped in 'ammo' boxes of 2000 pieces for the range 1M1 to 100M
and in boxes of 1000 for the range 101M to 1G0. All other case sizes are packed loose in polythene bags in
quantities of 50 pieces per bag. Please consult the Sales Office for tape/boxed product up to 2 watt case size.
Special Requirements
Other values and power ratings are available. Contact the Sales Office for special requirements.
Performance Characteristics
The evaluation of the performance characteristics is carried out with reference to IEC
Specifications QC 400 000 and QC 400 100.
TEST REF
4.23
4.24
4.25.1
4.25.3
TEST REF
4.13
4.16
4.18
4.19
4.22
Long Term Tests ± (2% + 0.05 ohm)
Climatic sequence
Damp heat, steady state
Endurance at 70°C
Endurance at 155°C
Short Term Tests ± (1% + 0.05 ohm)
Overload
Robustness of terminations
Resistance to soldering heat
Rapid change of temperature
Vibration
How to Order
RGP
Common Part
RGP - Metal Glaze
Fixed Resistor
0207CH
Style
0207CH - 0.25W
50 - 0.5W
100 - 1W
200 - 2W
300 - 3W
400 - 4W
J
Tolerance
100R
Value
100 ohm
(100 ohms) 100R
1K0
(1000 ohms) 1K0
100K ohm
(100,000 ohms) 100K
J - 5%
TE Connectivity, TE connectivity (logo) and TE (logo) are trademarks.
Other logos, product and Company names mentioned herein may be trademarks of their respective owners.
While TE has made every reasonable effort to ensure the accuracy of the information in this datasheet, TE does not guarantee that it is error-free, nor does TE make any other
representation, warranty or guarantee that the information is accurate, correct, reliable or current. TE reserves the right to make any adjustments to the information contained herein
at any time without notice. TE expressly disclaims all implied warranties regarding the information contained herein, including, but not limited to, any implied warranties of merchantabili-
ty or fitness for a particular purpose. The dimensions in this datasheet are for reference purposes only and are subject to change without notice. Specifications are subject to change
without notice. Consult TE for the latest dimensions and design specifications.
