501-1407ER: DescriptionBoard Connector, 14 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Solder Terminal, Latch & Eject, Blue Insulator, Receptacle; CategoryThe connector The connector; File Size84KB，1 Pages; ManufacturerThomas & Betts Corporation; Websitehttp://www.tnb.com/

Download Datasheet Parametric View All

501-1407ER Overview

Board Connector, 14 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Solder Terminal, Latch & Eject, Blue Insulator, Receptacle

501-1407ER Parametric

Parameter Name	Attribute value
Maker	Thomas & Betts Corporation
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	LATCHED, LOW PROFILE
body width	0.362 inch
subject depth	0.404 inch
body length	1 inch
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	1000VAC V
Filter function	NO
IEC compliance	NO
Insulation resistance	1000000000 Ω
Insulator color	BLUE
insulator material	GLASS FILLED THERMOPLASTIC
MIL compliance	NO
Manufacturer's serial number	501
Plug contact pitch	0.1 inch
Match contact row spacing	0.1 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LATCH & EJECT
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	2.54 mm
Plating thickness	30u inch
polarization key	CENTER
Rated current (signal)	1 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.102 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	14
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

IDC Systems

Headers

LOW PROFILE

HEADERS WITH VERTICAL

RETAINER/EJECTOR

LATCHES, RIGHT ANGLE PINS

.100" x .100" CENTERS

LR92984

E60980

P

HYSICAL

P

ROPERTIES

I

NSULATION

M

ATERIAL

:

Glass filled thermoplastic

rated UL 94V-0

C

OLOR

:

Blue

C

ONTACT

M

ATERIAL

:

Phosphor bronze with 30µ inches

min. gold over 50µ inches min. nickel plating

.025 Sq. pin w/coined edges

E

LECTRICAL

P

ROPERTIES

C

URRENT

R

ATING

:

1 Amp

I

NSULATION

R

ESISTANCE

:

>1 x 10

9

Ohms @ 500 VDC

D

IELECTRIC

S

TRENGTH

:

>1000 VRMS @ sea level

E

NVIRONMENTAL

P

ROPERTIES

T

EMPERATURE

R

ATING

:

-55˚C TO 125°C

M

ATING

C

ONNECTORS

F

EMALE

S

OCKETS

:

See pages 9-13

A

CCESSORIES

P

OLARIZING

K

EY

:

See page 46

501 - XX XX

# of Positions

Tail Style

R

(PCB Retention)

E

(Ejector)

ES

Ejector for Strain Relief

Ordering Information

CATALOG NUMBERS

DIMENSION “D” IN MM (INCHES)

2.59 (.102)

4.19 (.165)

FOR 1.57 (.062)

FOR 3.18 (.125)

P.C. BOARDS

501-0607XX

501-1007XX

501-1207XX

501-1407XX

501-1607XX

501-2007XX

501-2407XX

501-2607XX

501-3007XX

501-3407XX

501-3607XX

501-4007XX

501-4407XX

501-5007XX

501-6007XX

501-6407XX

501-0617XX

501-1017XX

501-1217XX

501-1417XX

501-1617XX

501-2017XX

501-2417XX

501-2617XX

501-3017XX

501-3417XX

501-3617XX

501-4017XX

501-4417XX

501-5017XX

501-6017XX

501-6417XX

DIMENSIONS IN MM (INCHES)

NO.

OF

POS.

6

10

12

14

16

20

24

26

30

34

36

40

44

50

60

64

A

B

C

15.24 (.600)

20.32 (.800)

22.86 (.900)

25.40 (1.000)

27.94 (1.100)

33.02 (1.300)

38.10 (1.500)

40.64 (1.600)

45.72 (1.800)

50.80 (2.000)

53.34 (2.100)

58.42 (2.300)

63.50 (2.500)

71.12 (2.800)

83.82 (3.300)

88.90 (3.500)

7.11 (.280)

12.19 (.480)

14.73 (.580)

17.27 (.680)

19.81 (.780)

24.89 (.980)

29.97 (1.180)

32.51 (1.280)

37.59 (1.480)

42.67 (1.680)

45.21 (1.780)

50.29 (1.980)

55.37 (2.180)

62.99 (2.480)

75.69 (2.980)

80.77 (3.180)

5.08 (.200)

10.16 (.400)

12.70 (.500)

15.24 (.600)

17.78 (.700)

22.86 (.900)

27.94 (1.100)

30.48 (1.200)

35.56 (1.400)

40.64 (1.600)

43.18 (1.700)

48.26 (1.900)

53.34 (2.100)

60.96 (2.400)

73.66 (2.900)

78.74 (3.100)

Add suffix E for ejectors without strain relief; Add suffix ES for ejectors with strain relief

Add “R” to part number for PCB retention feature.

Thomas & Betts Electronics/OEM Division Tel: 901-252-5000 Fax: 901-252-1312

Dimensions shown are for reference only. Dimensions are in millimeters (inches).
