MCC
Features
TM
Micro Commercial Components
omponents
20736
Marilla
Street Chatsworth
!"#
$
% !"#
MD100S08M5
MD100S12M5
MD100S16M5
MD100S18M5
100
Amp
GLASS PASSIVATED
THREE PHASE
RECTIFIER BRIDGE
800~1800
Volts
M6
Lead Free Finish/RoHS Compliant (NOTE 1)("P" Suffix
designates RoHS Compliant. See ordering information)
Blocking Voltage:800 to 1800V
Heat transfer through aluminum oxide DBC ceramic
isolated metal baseplate
Glass passivated chip
Applications
Three phase rectifiers for power supplies
Rectifiers for DC motor field supplies
Battery charger rectifiers
C
M5
B
A
D
E
K
F
H
G
I
J
L
M
N
Circuit
+
~
~
~
-
DIM
A
B
C
D
E
F
G
H
I
J
K
L
M
N
DIMENSIONS
INCHES
MM
MIN
MAX
MIN
MAX
0.650
0.689
16.50
17.50
0.098
0.138
2.50
3.50
0.256
0.295
6.50
7.50
2.028
2.067
51.50
52.50
0.453
0.492
11.50
12.50
2.106
2.146
53.50
54.50
0.236
0.276
6.00
7.00
1.043
1.083
26.50
27.50
24.50
25.50
0.965
1.004
65.50
66.50
2.579
2.618
0.256
6.50
71.50
72.50
2.815
2.854
79.50
80.50
3.130
3.169
93.50
94.50
3.681
3.720
NOTE
Φ
Revision:
A
www.mccsemi.com
1 of
4
2015/12/17
