3 Watt
o Pi Input Filter
o Regulated Output
o Single & Dual Output
o Short Circuit Protection
o 1000 VDC I/O-Isolation
24 Pin DIL Package V
3000 VDC I/O-Isolation add Suffix „H3“
o Metal Case Available
MODEL NUMBER
INPUT VOLTAGE
OUTPUT
VOLTAGE
5 VDC
9 VDC
12 VDC
15 VDC
24 VDC
OUTPUT
CURRENT
600 mA
INPUT CURRENT
% EFF
NO LOAD
FULL LOAD
923 mA
70 mA
65
3VRS5N5M
3VRS5N9M
3VRS5N12M
3VRS5N15M
3VRS5N24M
5 VDC
3VRD5N5M
3VRD5N9M
3VRD5N12M
3VRD5N15M
3VRD5N24M
3VRS12N5M
3VRS12N9M
3VRS12N12M
3VRS12N15M
3VRS12N24M
12 VDC
3VRD12N5M
3VRD12N9M
3VRD12N12M
3VRD12N15M
3VRD12N24M
last up-date 02.06.2005
333 mA
250 mA
80 mA
200 mA
125 mA
±300 mA
±167 mA
±125 mA
35 mA
833 mA
72
±100 mA
±63 mA
600 mA
35 mA
333 mA
250 mA
40 mA
337 mA
74
300 mA
125 mA
±300 mA
±167 mA
±125 mA
25 mA
±100 mA
320 mA
78
±63 mA
40 mA
70 mA
15 mA
320 mA
78
20 mA
312 mA
80
357 mA
70
60 mA
811 mA
378 mA
357 mA
74
66
70
130 mA
25 mA
30 mA
923 mA
870 mA
857 mA
65
69
70
857 mA
70
±5 VDC
±9 VDC
±12 VDC
±15 VDC
±24 VDC
5 VDC
9 VDC
12 VDC
15 VDC
24 VDC
±5 VDC
±9 VDC
±12 VDC
±15 VDC
±24 VDC
3 Watt - 24 Pin DIL - Package V
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
2/4
MODEL NUMBER
INPUT VOLTAGE
OUTPUT
VOLTAGE
5 VDC
9 VDC
12 VDC
15 VDC
24 VDC
OUTPUT
CURRENT
600 mA
INPUT CURRENT
% EFF
NO LOAD
FULL LOAD
189 mA
25 mA
178 mA
66
70
3VRS24N5M
3VRS24N9M
3VRS24N12M
3VRS24N15M
3VRS24N24M
24 VDC
3VRD24N5M
3VRD24N9M
3VRD24N12M
3VRD24N15M
3VRD24N24M
333 mA
250 mA
30 mA
200 mA
125 mA
±300 mA
10 mA
25 mA
193 mA
72
169 mA
74
±5 VDC
±9 VDC
±12 VDC
±15 VDC
±24 VDC
160 mA
78
±167 mA
±125 mA
15 mA
±100 mA
±63 mA
25 mA
160 mA
78
156 mA
80
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
vertrieb@mrmultitronik.de
3 Watt - 24 Pin DIL - Package V
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
3/4
INPUT SPECIFICATIONS
Input Voltage Range
Input Filter
±10%
Pi Network
OUTPUT SPECIFICATIONS
Voltage Accuracy
Voltage Balance (Dual)
Temperature Coefficient
Ripple and Noise, 20MHz BW
Short Circuit Protection
Short Circuit Restart
Line Regulation
Load Regulation
±2% max.
±1%
±0.02%/°C max.
75 mV p-p max.
Continuous
Automatic
±0.5% max.
±0.5% max.
GENERAL SPECIFICATION
Efficiency
Isolation Voltage
Suffix "H3"
Isolation Resistance
Isolation Capacitance
Switching Frequency
Operating Temperature Range
Case Temperature
Storage Temperature Range
Humidity
Cooling
Case Material
Suffix "A"
MTBF (MIL-HDBK-217F)
Capacitive Load at Dual Output
±470 µF max.
Single
Dual
Single
Dual
see table
1000 VDC min.
3000 VDC min.
1.000 Mohms min.
60 pF
40 kHz
250 kHz
-40°C to +85°C
-40°C to +85°C
+95°C max.
-40°C to +125°C
Up to 90%, Non Condensing
Free-Air Convection
Non Conductive Black Plastic
Nickel-Coated Copper
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
vertrieb@mrmultitronik.de
3 Watt - 24 Pin DIL - Package V
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
4/4
MECHANICAL SPECIFICATIONS
CASE "V"
Non Conductive Black Plastic
PIN
1 & 24
2 & 23
3 & 22
9 & 16
10 & 15
11 & 14
12 & 13
PIN CONNECTIONS 1000 VDC
SINGLE
+INPUT
NC*
NC*
NO PIN
-OUTPUT
+OUTPUT
-INPUT
DUAL
+INPUT
-OUTPUT
COMMON
NO PIN
COMMON
+OUTPUT
-INPUT
*
Option "NO Pin" at Single Output add Suffix "NP"
to Part No.
Nickel-Coated Copper
PIN CONNECTIONS 3000 VDC
PIN
1&2
3 & 22
9 & 16
10 & 11
12
13
14
15
23 & 24
SINGLE
+INPUT
NO PIN
NO PIN
NO PIN
-OUTPUT
+OUTPUT
NO PIN
NO PIN
-INPUT
DUAL
+INPUT
NO PIN
NO PIN
COMMON
NO PIN
-OUTPUT
NO PIN
+OUTPUT
-INPUT
Application Note:
Please don't operate in parallel use.
N O T I C E:
The information in this document has been carefully checked. However, no responsibility is assumed for inaccuracies!
Specifications can be changed without notice. The latest and most complete information can be found on our website.
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
