CS201
www.vishay.com
Vishay Dale
Thick Film Capacitor Networks, Single-In-Line,
Conformal Coated SIP
FEATURES
Isolated and bussed schematics available
X7R and C0G capacitors available
Multiple isolated capacitors
Multiple capacitors, common ground
Custom design capability
“D” 0.300" (7.62 mm) package height
(maximum)
• Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
•
•
•
•
•
•
Available
Available
Note
*
This datasheet provides information about parts that are RoHS-compliant and / or parts that are non RoHS-compliant. For example, parts
with lead (Pb) terminations are not RoHS-compliant. Please see the information / tables in this datasheet for details
STANDARD ELECTRICAL SPECIFICATIONS
VISHAY
DALE
MODEL
CS201
CS201
CS201
PROFILE
D
D
D
SCHEMATIC
1
3
4
CAPACITANCE
RANGE
C0G
(1)
33 pF to 3900 pF
33 pF to 3900 pF
33 pF to 3900 pF
X7R
470 pF to 0.1 μF
470 pF to 0.1 μF
470 pF to 0.1 μF
CAPACITANCE
TOLERANCE
(-55 °C to +125 °C)
±%
10, 20
10, 20
10, 20
CAPACITANCE
VOLTAGE
at 85 °C
V
DC
50
50
50
Note
(1)
C0G capacitors may be substituted for X7R capacitors
TECHNICAL SPECIFICATIONS
PARAMETER
UNIT
CS201
C0G
X7R
± 15 %
MATERIAL SPECIFICATIONS
Marking resistance
to solvents
Solderability
Permanency testing per MIL-STD-202,
method 215
Per MIL-STD-202, method 208E
High alumina, epoxy coated
(flammability UL 94 V-0)
Phosphorus-bronze, solder plated
Pin #1 identifier, Dale or D, part number
(abbreviated as space allows), date code
Temperature coefficient
(-55 °C to +125 °C)
Dissipation factor
(maximum)
ppm/°C
or
± 30 ppm/°C
%
±%
0.15
Body
Terminals
2.5
Marking
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: 20108D1C103K5P (preferred part numbering format)
2
GLOBAL
MODEL
0
1
0
PACKAGE
HEIGHT
D
= “D”
profile
8
D
1
C
1
0
3
K
5
P
PIN
COUNT
SCHEMATIC CHARACTERISTIC
1
3
4
0
= special
C
= C0G
X
= X7R
S
= special
CAPACITANCE
TOLERANCE VOLTAGE
VALUE
(in picofarads) 2
digit significant
figure, followed
by a multiplier
330
= 33 pF
392
= 3900 pF
104
= 0.1 μF
K
= ± 10 %
M
= ± 20 %
S
= special
PACKAGING
SPECIAL
201
= CS201 04 to 18 pin
available
04
= 4 pin
08
= 8 pin
18
= 18 pin
5
= 50 V
E
= lead (Pb)-free, Blank = standard
bulk
S
= special
(dash number)
P
= tin / lead, bulk (up to 3 digits)
From
1 to 999
as applicable
Historical Part Number example: CS20108D1C103K5 (will continue to be accepted)
CS201
HISTORICAL
MODEL
08
PIN
COUNT
D
PACKAGE
HEIGHT
1
SCHEMATIC
C
CHARACTERISTIC
103
CAPACITANCE
VALUE
K
TOLERANCE
5
VOLTAGE
P03
PACKAGING
Note
• For additional information on packaging, refer to the Through-hole Network Packaging document (www.vishay.com/doc?31542)
Revision: 24-Jan-2019
Document Number: 31522
1
For technical questions, contact:
ff2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
CS201
www.vishay.com
DIMENSIONS
in inches (millimeters)
0.085 (2.160)
Typ.
L
Max.
0.050 (1.27)
Typ.
Vishay Dale
0.135 (3.43)
Max.
0.300 (7.62)
Max.
Seating Plane
for 0.040 (1.016) Ø Hole
0
.
007 (0.178) Ref.
0.020 ± 0.002
(0.508 ± 0.051)
0.100 ± 0.005 (2.54 ± 0.127)
Non-Cumulative
at Point of Egress
0.050 (1.27)
0.010 ± 0.002
(0.254 ± 0.051)
0.135 + 0.015 - 0.010
(3.43 + 0.381 - 0.254)
Pin #1 is extreme left-hand terminal on side with marking.
NUMBER
OF PINS
4 pin
5 pin
6 pin
7 pin
8 pin
L
MAXIMUM
0.400 (10.16)
0.500 (12.70)
0.600 (15.24)
0.700 (17.78)
0.800 (20.32)
NUMBER
OF PINS
9 pin
10 pin
11 pin
12 pin
13 pin
L
MAXIMUM
0.900 (22.86)
1.000 (25.40)
1.100 (27.94)
1.200 (30.48)
1.300 (33.02)
NUMBER
OF PINS
14 pin
15 pin
16 pin
17 pin
18 pin
L
MAXIMUM
1.400 (35.56)
1.500 (38.10)
1.600 (40.64)
1.700 (43.18)
1.800 (45.72)
SCHEMATICS
Schematic 1
Schematic 3
Schematic 4
1
2
3
4
5
6
n-1
n
1
2
3
4
5
6
7
8
n-1
n
Common Bus - 1 Ground Lead
Isolated Capacitor Sections
1
2
3
4
n-1 n
Common Bus - 2 Ground Leads
Revision: 24-Jan-2019
Document Number: 31522
2
For technical questions, contact:
ff2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
