706-AG2D-ES Product Details
Live Product Chat
Product Photo
DIP Sockets
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
706-AG2D-ES
(1437542-8)
T E I nternal N umber: 1 4 3 7 5 4 2 - 8
Product Highlights:
l
DIP Socket
l
Number of Positions = 6
l
Row-to-Row Spacing = 7.62 mm
l
Through Hole C ontact Termination Type
l
Mount Style = Vertical
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
C ARRIER ASS'Y. LEAD SOC KET
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= DIP Socket
l
Number of Positions
= 6
l
Profile = Standard
l
Frame Style
= Disposable C arrier
l
Leg Style
= Straight
l
Sleeve Material = Machined Brass
l
Product Series = 700 Series
l
C omment = Economy Series
Electrical Characteristics:
l
Insulation Resistance (M?) = 5,000
l
C ontact Resistance (m?) = 10
l
C ontact Rating = 3A
Termination Related Features:
l
Termination Post Length (mm [in])
= 3.18 [0.125]
l
Solder Tail C ontact Plating = Tin-Lead
Body Related Features:
l
Row-to-Row Spacing (mm [in])
= 7.62 [0.300]
l
Mount Style
= Vertical
l
C enterline (mm [in])
= 2.54 [0.100]
Contact Related Features:
l
C ontact Termination Type
= Through Hole
l
C ontact Base Material
= Beryllium C opper
l
C ontact Mating Area Plating Material
= Gold
l
C ontact Style
= Screw Machine
l
Mating C ontact Type
= Four-Fingered
Configuration Related Features:
l
Height Above PC Board (mm [in])
= 4.20 [0.165]
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
Conditions for Usage:
l
Temperature Range (?C ) = -55 – +125
Operation/Application:
l
Application = Production
Packaging Related Features:
l
Packaging Method
= Package
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
