DM74ALS153 Dual 1-of-4 Line Data Selector/Multiplexer
April 1984
Revised February 2000
DM74ALS153
Dual 1-of-4 Line Data Selector/Multiplexer
General Description
This Data Selector/Multiplexer contains full on-chip decod-
ing to select one-of-four data sources as a result of a
unique two-bit binary code at the Select inputs. Each of the
two Data Selector/Multiplexer circuits have their own sepa-
rate Data and Strobe inputs and a non-inverting output
buffer. The Select inputs A and B are common to both sec-
tions. The Strobe inputs, when at the HIGH level, disable
their associated data inputs and force the corresponding
output to the LOW state. The Select input buffers incorpo-
rate internal overlap features to ensure that select input
changes do not cause invalid output transients.
Features
s
Advanced oxide-isolated, ion-implanted Schottky TTL
process
s
Switching performance is guaranteed over full tempera-
ture and V
CC
supply range
s
Pin and functional compatible with LS family counterpart
s
Improved output transient handling capability
Ordering Code:
Order Number
DM74ALS153M
DM74ALS153SJ
DM74ALS153N
Package Number
M16A
M16D
N16E
Package Description
16-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150 Narrow
16-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
16-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300 Wide
Devices also available in Tape and Reel. Specify by appending the suffix letter “X” to the ordering code.
Connection Diagram
Function Table
Select
Inputs
B
X
L
L
L
L
H
H
H
H
A
X
L
L
H
H
L
L
H
H
C0
X
L
H
X
X
X
X
X
X
Data Inputs
C1
X
X
X
L
H
X
X
X
X
C2
X
X
X
X
X
L
H
X
X
C3
X
X
X
X
X
X
X
L
H
Strobe
G
H
L
L
L
L
L
L
L
L
Output
Y
L
L
H
L
H
L
H
L
H
Select inputs A and B are common to both sections.
H
=
HIGH Level
L
=
LOW Level
X
=
Don't Care
© 2000 Fairchild Semiconductor Corporation
DS006204
www.fairchildsemi.com
DM74ALS153
Absolute Maximum Ratings
(Note 1)
Supply Voltage
Input Voltage
Operating Free Air Temperature Range
Storage Temperature Range
Typical
θ
JA
N Package
M Package
78.0°C/W
107.0°C/W
7V
7V
0°C to
+70°C
−65°C
to
+150°C
Note 1:
The “Absolute Maximum Ratings” are those values beyond which
the safety of the device cannot be guaranteed. The device should not be
operated at these limits. The parametric values defined in the Electrical
Characteristics tables are not guaranteed at the absolute maximum ratings.
The “Recommended Operating Conditions” table will define the conditions
for actual device operation.
Recommended Operating Conditions
Symbol
V
CC
V
IH
V
IL
I
OH
I
OL
T
A
Supply Voltage
HIGH Level Input Voltage
LOW Level Input Voltage
HIGH Level Output Current
LOW Level Output Current
Free Air Operating Temperature
0
Parameter
Min
4.5
2
0.8
−2.6
24
70
Nom
5
Max
5.5
Units
V
V
V
mA
mA
°C
Electrical Characteristics
over recommended operating free air temperature range. All typical values are measured at V
CC
=
5V, T
A
=
25°C.
Symbol
V
IK
V
OH
V
OL
I
I
I
IH
I
IL
I
O
I
CC
Parameter
Input Clamp Voltage
HIGH Level
Output Voltage
LOW Level
Output Voltage
Input Current at
Max Input Voltage
High Level Input Current
Low Level Input Current
Output Drive Current
Supply Current
Conditions
V
CC
=
4.5V, I
IN
= −18
mA
V
CC
=
4.5V, I
OH
=
Max
I
OH
= −400 µA,
V
CC
=
4.5V to 5.5V
V
CC
=
4.5V
V
CC
=
5.5V, V
IN
=
7V
V
CC
=
5.5V, V
IN
=
2.7V
V
CC
=
5.5V, V
IN
=
0.4V
V
CC
=
5.5V, V
OUT
=
2.25V
V
CC
=
5.5V
All Inputs
=
4.5V
−30
7.5
I
OL
=
24 mA
2.4
V
CC
−
2
0.35
0.5
0.1
20
−0.1
−112
14
3.2
Min
Typ
Max
−1.5
Units
V
V
V
V
mA
µA
mA
mA
mA
Switching Characteristics
over recommended operating free air temperature range.
Symbol
t
PLH
t
PHL
t
PLH
t
PHL
t
PLH
t
PHL
Parameter
Propagation Delay Time
LOW-to-HIGH Level Output
Propagation Delay Time
HIGH-to-LOW Level Output
Propagation Delay Time
LOW-to-HIGH Level Output
Propagation Delay Time
HIGH-to-LOW Level Output
Propagation Delay Time
LOW-to-HIGH Level Output
Propagation Delay Time
HIGH-to-LOW Level Output
Conditions
V
CC
=
4.5V to 5.5V
C
L
=
50 pF
R
L
=
500Ω
From
Select
Select
Data
Data
Strobe
Strobe
To
Y
Y
Y
Y
Y
Y
Min
5
5
3
4
5
5
Max
21
21
10
15
18
18
Units
ns
ns
ns
ns
ns
ns
3
www.fairchildsemi.com
