SAFEB1G57KE0F00R12 datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> filter> SAFEB1G57KE0F00R12

SAFEB1G57KE0F00R12: Descriptionfilter saw 1.57ghz gps smd; CategoryAnalog mixed-signal IC filter; File Size407KB，4 Pages; ManufacturerMurata; Websitehttps://www.murata.com

Download Datasheet Parametric Compare View All

SAFEB1G57KE0F00R12 Overview

filter saw 1.57ghz gps smd

SAFEB1G57KE0F00R12 Parametric

Parameter Name	Attribute value
Maker	Murata
Reach Compliance Code	unknown
Other features	TAPE AND REEL
Center frequency or cutoff frequency (fo/fc)	1575.5 MHz
filter type	SAW FILTER
high	0.6 mm
input resistance	50 OHM
Maximum insertion loss	1.3 dB
length	1.35 mm
Manufacturer's serial number	SAFEB1G57KE0F00
Installation type	SURFACE MOUNT
Number of functions	1
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Output impedance	50 OHM Ω
physical size	L1.35XB1.05XH0.6 (mm)/L0.053XB0.041XH0.024 (inch)
width	1.05 mm

Preview

Download Datasheet

View All

SAW FILTER FOR GPS

Murata part number :SAFEB1G57KE0F00

Package Dimensions

Specification

Item

Nominal Center Frequency(f c)

1.35±0.05

1.05±0.05

Specif ication

-30 to 85°C

25±2°C

1575.5MHz

1.3 dB max.

1.2 dB max.

0.95 dB

typ.

Insertion Loss

(1573.92 to 1576.92MHz)

A bsolute A ttenuation

(0.20)

0.6max.

Dot Marking(φ0.3)

J T

0.1 to

250 to

810 to

960 to

1429 to

250 MHz

810 MHz

960 MHz

1429 MHz

1453 MHz

40 dB min.

41 dB min.

40 dB min.

37 dB min.

1.1 dB min.

40 dB min.

43 dB min.

44 dB min.

43 dB min.

45 dB min.

40 dB min.

30 dB min.

0.6dB max.

40 dB min.

41 dB min.

40 dB min.

37 dB min.

1.1 dB min.

40 dB min.

43 dB min.

44 dB min.

43 dB min.

45 dB min.

40 dB min.

30 dB min.

0.5dB max.

48 dB

42 dB

53 dB

43 dB

1.6 dB

46 dB

47 dB

50 dB

44 dB

33 dB

0.03 dB

1453 to 1525.42 MHz

1525 to

1625 to

1710 to

1749.9 to

1785 to

1920 to

1990 to

2170 to

2700 to

1560 MHz

1710 MHz

1749.9 MHz

1785 MHz

1920 MHz

1990 MHz

2170 MHz

2700 MHz

6000 MHz

5-0.325±0.050

2-0.25±0.05

(0.075)

10)

11)

12)

(2)

(1)

(5)

(3)

(0.05)

2-0.25±0.05

(4)

5-0.25±0.05

2-0.25±0.05

13)

14)

15)

Ripple Deviation

(1573.92 to 1576.92MHz)

Marking

: Laser Printing

(1) : Input

(4) : Output

Others : Ground

Unit : mm

V SWR

(1573.92 to 1576.92MHz)

Input/Output Impedance (nominal)

Input Signal Level

1.7 max.

1.5 max.

Ω

1.2

50mW (+17dBm), 2000 hours

Sep. 27, 2006

1/4
