KBU802 Overview

Bridge Rectifier Diode, 8A, 200V V(RRM),

KBU802 Parametric

Parameter Name	Attribute value
Maker	FCI / Amphenol
Reach Compliance Code	unknown
Configuration	BRIDGE, 4 ELEMENTS
Diode type	BRIDGE RECTIFIER DIODE
Maximum forward voltage (VF)	1 V
Maximum non-repetitive peak forward current	300 A
Number of components	4
Maximum operating temperature	125 °C
Maximum output current	8 A
Maximum repetitive peak reverse voltage	200 V
surface mount	NO
Base Number Matches	1

Preview

Download Datasheet

View All

Data Sheet

8.0 Amp

SINGLE PHASE SILICON BRIDGE

Mechanical Dimensions

KBU800 . . . 810 Series

Description

Mechanical Data:

Weight - 0.3 Ounces. Mounting Torque -

5.1 lbs. Mounting Position - Any.

Features

COMPACT SIZE

LOW LEAKAGE CURRENT

300 AMP SURGE OVERLOAD RATING

MEETS UL SPECIFICATION 94V-0

Electrical Characteristics @ 25

Maximum Ratings

Peak Repetitive Reverse Voltage...V

RRM

RMS Reverse Voltage...V

R(rms)

DC Blocking Voltage...V

Average Forward Rectified Current...I

F(av)

= 25°C

KBU800 . . . 810 Series

KBU800

KBU801

100

KBU802

200

140

200

KBU804 KBU806 KBU808

400

280

400

600

420

600

800

560

800

KBU810

1000

700

1000

Units

Volts

Amps

Volts

............................................. 8.0 ...............................................

............................................. 3 0 0 ...............................................

Non-Repetitive Peak Forward Surge Current...I

FSM

8.3 mS Single ½ Sine Wave Imposed on Rated Load

Rating for Fusing (T < 8.3mS)

Forward Voltage...V

Per Leg @ 8.0 Amps

DC Reverse Current...I

@ Rated DC Blocking Voltage

= 25°C

= 125°C

............................................. 167 ...............................................

............................................. 1.0 ...............................................

............................................. 1 0 ...............................................

µAmps

............................................. 1.0 ............................................... mAmps

............................................. 6.0 ...............................................

............................................. 8.0 ...............................................

< ....................

210

................ > < ............ 9 0 ............. >

......................................... -55 to 150 ..........................................

°C

/ W

°C

/ W

°C

Typical Thermal Resistance...R

θJC

(Alum Heat Sink)

Thermal Resistance...R

θJA

(Free Air)

Typical Junction Capacitance...C

Operating & Storage Temperature Range...T

, T

STRG

Page 3-23
