LP1000M250-3050: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum, 250V, 20% +Tol, 20% -Tol, 1000uF; CategoryPassive components capacitor; File Size78KB，3 Pages; ManufacturerYELLOW STONE CORP.; Websitehttp://www.ystone.com.tw/

Download Datasheet Parametric View All

LP1000M250-3050 Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum, 250V, 20% +Tol, 20% -Tol, 1000uF

LP1000M250-3050 Parametric

Parameter Name	Attribute value
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
capacitance	1000 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	30 mm
dielectric materials	ALUMINUM
length	50 mm
Manufacturer's serial number	LP(250V)
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
Package form	Radial
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	250 V
series	LP(250V)
Terminal pitch	10 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Aluminum Electrolytic Capacitors

Features

‧PCB

Snap-In type 85℃

‧Directly

mountable on printed circuit board without holders.

‧Terminal

spacing fixed at 10mm for pc board plug in.

Specification

Items

Capacitance Tolerance

Rated Voltage Range

Capacitance Range

Operating Temperature Range

Leakage Current (at 25℃)

LP

Series

Performance

(at 120Hz, 25

℃)

16 to 100 VDC

160 to 450 VDC

470 to 47000 uF

47 to 2200 uF

-25 to 85℃

-40 to + 85℃

I≦0.03 CV or 8 uA , whichever is greater.

After 5 minutes application of working voltage.

I= Leakage current (uA), C= Rated capacitance (uF), V= Rated voltage (V)

Rate Voltage 16 25 35 50 63 100 160 200 250 350 400 450

tanδ (max)

0.50 0.40 0.35 0.30 0.25 0.20 0.15 0.15 0.15 0.15 0.15 0.15

±20

％　

Dissipation Factor

(Tan

δ

at 120Hz, 25℃)

Low Temperature

characteristics (at 120Hz)

Impedance ration shall not exceed the values given in the table below.

Rate Voltage

16 25 35 50 63 100 160 200 250 350 400 450

-25℃/25℃

-40℃/25℃

4

15

3

10

3

8

2

6

2

6

2

5

4

8

4

10

4

16

4

18

8

20

Load Life

Shelf Life

After 2000 hours application of W.V. at 85℃.

the capacitor shall meet the followin limits.

Capacitance change

：

≦±25%

of initial value

Dissipation factor

：

≦200%

of initial specified value

Leakage Current

：

≦Initial

specified value

After storage for 1000 hours at 85℃, with no voltage applied and being stabilixed at

+ 25℃, Capacitor shall meet the limit specifed in load life.

Freq.(Hz)

60 (50)

0.90

0.81

0.77

120

1.00

70

1.50

500

1.13

1.17

1.16

1K

1.19

1.32

1.30

85

1.00

10K up

1.20

1.45

1.41

Ripple Current &

Frequency Multipliers

W.V.(V)

Under 100

160 to 250

350 to up

Temperature (℃)

Multiplier

Ripple Current &

Temperature Multipliers

1
