2W TO 25 WATT VERTICAL MOUNT RESISTORS
RESISTORS CAPACITORS COILS DELAY LINES
PV SERIES
- 2 Terminal
PVH SERIES
- 4 Terminal
PWV SERIES
- Bracket Mount
Industry’s widest range! 1mΩ-1M, to ±.05% 10ppm!
Built-in standoffs minimize heat transfer to P.C.B.
Available on exclusive
SWIFT
TM
delivery program!
OPTIONS
Option X - Non-Inductive
Option WW or M (wirewound or film element)
Option P - Increased pulse capability
Option FF- Fuse within 10S @50x rated W (custom avail)
Option E - Low thermal EMF design
Option B - Increased power (refer to chart below)
Numerous modifications avail: custom marking,
TC’s to +6000ppm, various lead wire sizes, burn-in, etc.
SERIES
Wattage
PV
Std (Opt.B)
PV2
2W (3W)
PV3
3W (4W)
PV5
5W (6W)
PV7
7W (10W)
P V 10
10W (12W)
PV10S 10W (12W)
PV10A 10W (12W)
SERIES
PVH
PVH2
PVH3
PVH5
PVH7
PVH10
PVH10S
PVH10A
RoHS
Term.W is
RoHS
compliant &
260°C
compatible
RCD
PV7
RCD
PV5
Significant space savings compared to axial-lead types!
PV, PVH, and PWV resistors are designed for power applications where
space is at a premium. The PV series offers lowest cost for medium
power applications. PVH series are similar except in 4-terminal Kelvin
design (to cancel lead wire effect). PWV bracketed resistors enable
higher power levels and superior performance in applications involving
shock and vibration. The ceramic construction is fireproof and resistant
to moisture & solvents. The internal element is wirewound on lower values,
power film on higher values (depending on options, e.g. opt. P parts are
always WW). If a specific construction is preferred, specify opt.’WW’ for
wirewound, opt.’M’ for power film (not available in all values).
D
E
±.04 [1] ±.005[.12]
.197 [5] .028 [.7]
.197 [5] .031 [.8]
.197 [5] .031 [.8]
.197 [5] .031 [.8]
.197 [5] .031 [.8]
.290 [7.4] .036 [.9]
.197 [5] .036 [.9]
F
(Nom)
.036 [.9]
.040 [1]
.040 [1]
.040 [1]
.040 [1]
.048 [1.2]
.048 [1.2]
D
C
R
5
V1
PW
PV
D
H1
0
RC
Max.
Max.
Voltage* Current*
80V
14A
150V
17A
250V
22A
350V
26A
500V
32A
400V
32A
400V
32A
Std Resis
R an g e
.005
Ω
to 1M
.005
Ω
to 1M
.005
Ω
to 1M
.005
Ω
to 1M
.005
Ω
to 1M
.005
Ω
to 1M
.005
Ω
to 1M
A
B
C
±.04 [1.0] ±.04 [1.0] ±.062 [1.6]
.450 [11.4] .300 [7.6] .800 [20.3]
.475 [12.1] .350 [8.9] .980 [24.9]
.500 [12.7] .360 [9.2] 1.00 [25.4]
.500 [12.7] .400 [10] 1.52 [38.6]
.500 [12.7] .400 [10] 2.02 [51.3]
.625 [15.9] .500 [12.7] 1.38 [35.0]
.625 [15.9] .500 [12.7] 1.38 [35.0]
←
A
→
↑
C
B
↓
D
F
(dia)
Mounting Layout
E
→
←
.125”
min
Wattage
Max. Max Current* Std Resis
A
B
C
D
E
Std (Opt.B) Voltage* Std (Opt.B)
R an g e
±.04 [1.0] ±.04 [1.0] ±.062 [1.6] ±.04 [1] ±.024[.6]
2W (3W)
80V
14A (17A) .001
Ω
to 10K .450 [11.4] .300 [7.6] .800 [20.3] .197 [5] .075 [1.91]
3W (5W)
150V
17A (22A) .001
Ω
to 25K .475 [12.1] .350 [8.9] .980 [24.9] .197 [5] .100 [2.54]
5W (7W)
250V
22A (26A) .001
Ω
to 30K .500 [12.7] .400 [10] 1.00 [25.4] .197 [5] .100 [2.54]
7W (10W)
350V
26A (32A) .001
Ω
to 50K .500 [12.7] .400 [10] 1.52 [38.6] .197 [5] .100 [2.54]
10W (12W) 500V
32A (40A) .001
Ω
to 250K .500 [12.7] .400 [10] 2.02 [51.3] .197 [5] .100 [2.54]
10W (12W) 400V
32A (40A) .001
Ω
to 250K .625 [15.9] .500 [12.7] 1.38 [35.0] .290 [7.4] .125 [3.18]
10W (12W) 400V
32A (40A) .001
Ω
to 250K .625 [15.9] .500 [12.7] 1.38 [35.0] .197 [5] .125 [3.18]
F ± .003"
Std (Opt.B)
.032 (.040)
.032 (.040)
.032 (.040)
.032 (.040)
.032 (.040)
.032 (.040)
.032 (.040)
←
A
→
↑
C
B
→ ←
F
D
.040”
E
↓
.125”
min
(.048 opt.B)
E
Mounting Layout
SERIES
Max.
Max
Std Resis
Wattage
PWV
Voltage* Current*
R an g e
PWV5
5
200V
22A
.01
Ω
to 1M
PWV7
7
350V
26A
.01
Ω
to 1M
PWV10
10
500V
32A
.01
Ω
to 1M
PWV15
15
540V
32A
.01
Ω
to 150K
PWV20
20
600V
32A
.01
Ω
to 150K
PWV25
25
600V
32A
.01
Ω
to 150K
A
Max
1.40 [35.6]
1.86 [47.3]
2.46 [62.5]
2.46 [62.5]
3.02 [76.7]
3.02 [76.7]
B
±.04 [1.0]
.400 [10]
.400 [10]
.400 [10]
.500 [12.7]
.500 [12.7]
.500 [12.7]
C
D
E
±.04 [1.0] ±.02 [0.5] ±.06 [1.5]
.400 [10] .060 [1.5] .200 [5]
.400 [10] .060 [1.5] .200 [5]
.400 [10] .060 [1.5] .200 [5]
.530 [13.5] .100 [2.5] .265 [6.7]
.580 [14.7] .100 [2.5] .275 [7.0]
.580 [14.7] .100 [2.5] .275 [7.0]
F
±.06 [1.5]
.200 [5]
.200 [5]
.200 [5]
.265 [6.7]
.295 [7.5]
.295 [7.5]
F
lead is
terminated
to metal
bracket
.036”
±.005
.022”
E
A
.125”
min
.
B
* Units not to exceed wattage, voltage, or current rating, whichever is less. Voltage determined by E=
√
PR , E not to exceed max
voltage rating. Multiply voltage rating by 0.7 for Opt. X. Increased voltage & current ratings available (up to 1KV, 100A).
B
C
E
D(3)
.05” dia.
.032x.08” 5-15W, .05x.12” 20-25W (3)
TYPICAL PERFORMANCE CHARACTERISTICS
Res. Range
.001-.0049
Ω
.005-.0099
Ω
.01-.024
Ω
.025-.049
Ω
.05-.099
Ω
.1 - .99
Ω
1Ω & above
PV &PWV Std (Best)
PVH Std (Best)
N/A
1200ppm (50ppm)
800ppm (50ppm)
600ppm (25ppm)
600ppm (50ppm)
200ppm (25ppm)
500ppm (30ppm)
150ppm (25ppm)
400ppm (20ppm)
90ppm (10ppm)
350ppm (20ppm)
50ppm (10ppm)
200ppm (10ppm)
20ppm (5ppm)
-55° to +220° C (275° C avail)
1000V
3X rated wattage (Opt. WW = 5X)
3.0%
1.0%
3.0%
Opt.X
≤
5W:
≤
50
Ω
=.2uH max,
>
50
Ω
=.37uH max
Opt. X
≥
7W:
≤
50
Ω
=.3uH max,
>
50
Ω
= .6uH max
125 to 220°C typ at full rated power
Derate by .513%/°C above 25° C
Mounting Layout
Temp. Coef.
PPM/°C
(25 ~100/°C)
P/N DESIGNATION:
PV10
- 100 - J B
W
Operating Temp.
Dielectric Strength
5 Sec. overload (
≤
1.5x max V)
Moisture Resistance
High Temp. Exposure
Load Life (1000 hours)
Opt X Inductance (reduced
inductance levels avail. to 67nH)
Temperature Rise
Derating (W, V, A)
RCD Type
Options:
X, WW, P, M, FF, E, B
(Leave blank if standard)
Resis.Code .05%-1%:
3 signif. figures & multiplier, e.g. R001=.001Ω,
R010=.01Ω, R100=.1Ω, 1R00=1Ω, 10R0=10Ω, 1000=100Ω, 1001=1K.
Resis.Code 2%-10%:
2 signif. figures & multiplier, e.g. R001=.001Ω,
R01=0.01Ω, R10=0.1Ω, 1R0=1Ω, 100=10Ω, 101=100Ω, 102=1K.
Tolerance:
A=0.05%, B=0.1%, C=0.25%, D=0.5%,
F=1%, G=2%, J=5%(std), K=10%
Packaging:
B=bulk (standard)
Optional TC:
10=10ppm, 20=20ppm, 50=50ppm, 101=100ppm,
201=200ppm, etc. (leave blank if standard)
Termination:
W= Lead-free, Q= Tin/Lead (leave blank if either is acceptable,
in which case RCD will select based on lowest price and quickest delivery)
RCD Components Inc,
520 E.Industrial Park Dr, Manchester, NH, USA 03109
rcdcomponents.com
Tel: 603
-
669
-
0054 Fax: 603
-
669
-
5455 Email:sales@rcdcomponents.com
FA053D
Sale of this product is in accordance with GF-061. Specifications subject to change without notice.
