SOMDIMM‐LPC2478
Users Manual
For use with
Touch Screen LCD Kit
Copyright ©2009, Future Designs, Inc., All Rights Reserved
Table of Contents
1.
2.
3.
4.
5.
6.
7.
8.
9.
Introduction ___________________________________________________________________________________ 4
LPC2478 SOMDIMM Block Diagram ________________________________________________________________ 4
Functional Description __________________________________________________________________________ 5
ESD Warning __________________________________________________________________________________ 5
Requirements _________________________________________________________________________________ 5
SOMDIMM‐LPC2478 Power Requirements __________________________________________________________ 5
Setting up the Hardware _________________________________________________________________________ 6
Demonstration Software Main Menu _______________________________________________________________ 7
PC to Demonstration Network Configuration ________________________________________________________ 8
_
10. Setting up a Slideshow _________________________________________________________________________ 10
11. Board Layout _________________________________________________________________________________ 11
12. DK‐TS‐KIT System Functional Block Diagram ________________________________________________________ 12
13. I/O Connector Descriptions ______________________________________________________________________ 13
JTAG Connector – J3 _____________________________________________________________________________ 13
MicroSD Connector – J2 __________________________________________________________________________ 14
ISP Connector – J5 _______________________________________________________________________________ 14
14. On Board Functions ____________________________________________________________________________ 15
Ethernet PHY – U8 _______________________________________________________________________________ 15
MicroSD – J2 ___________________________________________________________________________________ 15
Reset Generator – U3 ____________________________________________________________________________ 15
Serial EEPROM – U2 _____________________________________________________________________________ 15
_
15. 200‐pin SOMDIMM Connector Details – J4 _________________________________________________________ 16
16. SOMDIMM Installation _________________________________________________________________________ 19
17. SOMDIMM Socket Details _______________________________________________________________________ 19
18. Mechanical Details ____________________________________________________________________________ 20
19. Software ____________________________________________________________________________________ 21
20. Configuring Rowley CrossWorks CrossStudio for ARM® for J‐Link Flashing_________________________________ 23
21. Functional Test Software _______________________________________________________________________ 24
_
Configuring the Functional Test setup _____________________________________________________________ 24
Running Functional Test ________________________________________________________________________ 24
Installing the Demonstration Software via Flash Magic ________________________________________________ 25
22. Schematics ___________________________________________________________________________________ 26
23. Table of Figures _______________________________________________________________________________ 26
ii
Information in this document is provided solely to enable the use of Future Designs products. FDI assumes no liability whatsoever, including infringement of
any patent or copyright. FDI reserves the right to make changes to these specifications at any time, without notice. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of Future Designs,
Inc. 2702 Triana Blvd, Huntsville, AL 35805.
For more information on FDI or our products please visit www.teamfdi.com.
NOTE: The inclusion of vendor software products in this kit does not imply an endorsement of the product by Future Designs, Inc.
© 2009 Future Designs, Inc. All rights reserved.
uEZ™ is a registered trademark of Future Designs, Inc.
Microsoft, MS‐DOS, Windows, Windows XP, Microsoft Word are registered trademarks of Microsoft Corporation.
Other brand names are trademarks or registered trademarks of their respective owners.
FDI PN: MA00012
Revision: 3, 12/15/2009 4:38:00 PM
Printed in the United States of America
iii
1. Introduction
The SOMDIMM‐LPC2478 provides a quick and easy solution for implementing an ARM7TDMI‐S based design by
providing the basic functions necessary for a product on an easy to use SOMDIMM. The SOMDIMM uses an
industry standard 200 pin SO‐DIMM interface. These sockets are utilized by virtually every laptop on the market.
This SOMDIMM is compatible with FDI’s Family of Touch Screen LCD Kits but can also be used for custom platform
development or customer applications.
2. LPC2478 SOMDIMM Block Diagram
CARRIER USER I/O
TEMP, ACCEL, RTC, PBTNS, LEDS, EXTERNAL
DIMM MODULE BORDER
1KX8
SECURE
EEPROM
DEBUG
SERIAL
MINI
JTAG
5.0V
3.3V
3.3V
SPK
CAN
CONN
CAN1
TOUCH INTERFACE
I2S
16-BIT TFT
10/100
ETHERNET
KSZ8041
ETH
PHY
LPC2478
RMII
SPI_1
ARM7TDMI-S based
Microprocessor
UART2
RS232
SERIAL
USB
DEVICE
USBB DEVICE
MISC EXP GPIO
USB
HOST
USBA HOST
2MX32
SDRAM
TSOP
(4MX32 OPT)
DIMM MODULE BORDER
uSD
Socket
Figure 1 – LPC2478 SOMDIMM Block Diagram
4
3. Functional Description
SOMDIMM‐LPC2478
•
LPC2478 ARM7TDMI‐S based Microprocessor
•
2Mx32 SDRAM (8Mega‐bytes) optional up to 32Mx32
•
1KB I2C‐Serial EEPROM with Access Protection
•
10/100 Ethernet PHY
•
Micro SD Card Socket for up to 2Giga‐bytes storage (SDHC is not supported)
•
Mini JTAG
•
ISP Connector for use with USP‐ICP‐LPC2K
•
Power‐on Reset Generator
4. ESD Warning
The DK‐TS‐KIT shipped in a protective anti‐static package. The kit must not be subjected to high electrostatic
potentials. Damage may occur to the boards that will not be covered under warranty. General practice for working
with static sensitive devices should be followed when working with the DK‐TS‐KIT.
5. Requirements
The SOMDIMM‐LPC2478 requires a carrier board with a 200‐pin SO‐DIMM socket. The socket should have the key
at the 1.8V location (the SOMDIMM‐LPC2478 doesn’t require 1.8V). The CARRIER Board from Future Designs
provides this socket and should be utilized to develop your application for initial verification.
Example SO‐DIMM Socket Manufacturer and Part Number: TYCO 1473005‐4
Please refer to section 10 for the pin out details of the SOMDIMM Edge Finger.
6. SOMDIMM‐LPC2478 Power Requirements
The following power requirements were measured at room temperature at 72MHz operating clock rate:
Voltage
Booted at the uEZ Demo Screen
Observed Max
3.3V
200mA
208mA
5
