SURFBOARDS
THE BREADBOARDING MEDIUM FOR
R
TM
SURFACE MOUNT
33000 SERIES APPLICATION SPECIFIC ADAPTERS
IDS33205
REV 1-2012
MODEL
33205
B
ACCEPTS
THESE
DEVICES
PARTIAL
LISTING
SOT-23-5
SOT-25
SC-59-5
SC-74A
TSOP-5
TSOT-23-5
ANALOG
RJ-5, UJ-5
FAIRCHILD
TinyLogic
TM *1
BURR BROWN
PKG 331
MICREL
ITTYBITTY
TM ** 1
PANASONIC
Mini5-DA, Mini5-G1
ROHM
SMD5, SMT5, TSMT5
TEXAS INST.
Microgate
TM*** 1
DBV (R-PDSO-G5)
DDC (R-PDSO-G5)
TOSHIBA
SMV PKG.
ALWAYS CONSULT DEVICE DATA SHEET TO INSURE PROPER FIT
*TinyLogic is a Trademark of Fairchild Semiconductor Corp.
** Ittybitty is a Trademark of Micrel Semiconductor corp.
*** Microgate is a trademark of Texas Inst. Corp.
1 – In the SOT-23-5 / SC59-5 package.
FOR 5 LEAD
.95 MM
PITCH DEVICES
PINS ON .1 in.
CENTERS PROVIDE
COMPATIBILITY
WITH
BREADBOARDS
AND SOCKETS
A
DEVICE
FOOTPRINT
I
D
E
G
F
C
SINGLE-IN-LINE ( SIP ) PINS ON .100 in. CENTERS.
SEE PIN SPECS.
H
PIN SPECIFICATIONS / TOLERANCES
FIG.
A
B
C
D
E
F
G
H
I
INCHES
.400
.500
.100
.110
.0375
.050
.020
.060
.160
MM
10.16
12.7
2.54
2.79
.95
1.27
.508
1.52
4.06
NOTE:
BOARD HEIGHT
+-
.5mm .020in.
BOARD WIDTH
+- .
5mm .020in
.
SIP PIN SPACE
+- .20mm .008in.
PAD CENTERLINE
In Inches
A = .062 +- .006
B = .130 +- .010
C =.100 +- .005
D = .020 +- .004
E = .031 +-.005
DEVICE LEAD PITCH
PAD LENGTH
PAD WIDTH
GAP
MAX PIN WIDTH
BOARD
SPECIFICATIONS
RoHS
Compliant
EC 2002/95
BOARD MATERIAL:
.8mm, +-.13mm .031in+-..005 in.
Thick G-10 FR-4 Glass Epoxy or equivalent.
CIRCUITS:
1 oz. Copper with RoHS compliant Lead
Free solder coating. Patten Position on board +-
.5mm .020in.
TOLERANCES:
If not noted are +- 20%. Nominal values are given.
Controlling unit is Millimeters. Values rounded to nearest decimal. Slight
Variations due to manufacturing process can occur.
Copyright 1997-2012 by Capital Advanced Technologies, Inc. All rights reserved.
Surfboards is a registered trademark of Capital Advanced Technologies, Inc. The Breadboarding medium for surface mount, and the
Leaf Circuit Logo are trademarks of Capital Advanced Technologies, Inc. All other trademarks are the property of their respective owners. Specifications, availability, and price is subject to change without notice. All
information given is believed to be accurate but is not guaranteed. The user of information given or products represented by such information is responsible for determining the suitability of said information or products for
a given purpose. No inducement is intended or permission granted for infringement of any patent or unauthorized use of any intellectual property of Capital Advanced Technologies or others.
CAPITAL ADVANCED TECHNOLOGIES, INC.
CAROL STREAM, ILLINOIS. USA.
PHONE 630-690-1696
WWW.CapitalAdvanced.Com
FAX 630-690-2498
