LED Power Supplies

150W

LXV150

series

LED Power Supply

Constant Voltage Power Supplies

The LXV150 series of constant voltage LED power supplies from

Excelsys Technologies can deliver up to 150W of output power in an

extremely compact package size.

The LXV150 series of constant voltage power supplies provides a range of

output voltage solutions for specific LED requirements. With industry leading

efficiencies, and an extensive protection feature set, the LXV150 series

provides high reliability and high performance in a compact package

The LXV150 series carries the CE mark for safety and is also RoHS

compliant. For more details contact

sales@excelsys.com

Model

Number

LXV150-012S

LXV150-024S

LXV150-036S

LXV150-040S

LXV150-042S

LXV150-048S

LXV150-050S

LXV150-052S

LXV150-054S

LXV150-056S

LXV150-081S

LXV150-105S

Output

Voltage

12V

24V

36V

40V

42V

48V

50V

52V

54V

56V

81V

105V

Output

Current

12.5A

6.25A

4.17A

3.75A

3.57A

3.13A

3.00A

2.88A

2.78A

2.68A

1.85A

1.42A

Input

Voltage

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

90-264VAC

(3)

OVP

Max

16V

34V

48V

53V

55V

61V

63V

66V

69V

75V

100V

135V

OCP

Hiccup

110-180%

Efficiency

92.0%

93.0%

94.0%

93.0%

94.0%

LED Power

150W

LED POWER

next generation power

source

FEATURES

• Constant Voltage Power

• Active PFC (0.99 Typical)

• High Efficiency 94%

• IP67 Waterproof

• Active PFC (Typical 0.97)

• OVP, SCP, OTP

• -35 to 70°C deg operation

• Universal Input 90-264VAC

• UL8750 recognised

• EN61347-1, -2-13 compliant

Input Specifications

Parameter

Input Voltage Range

Input Frequency Range

Input Current

Inrush Current

Power Factor

Conditions/Description

Universal Input. see Note 3

100VAC in, 150W output

230VAC in, 25°C, Cold Start

220VAC, 110VAC

Min

Nom

0.96

Max

264/305

1.75

0.99

Units

VAC

Output Specifications

Parameter

Line Regulation

Load Regulation

Voltage Accuracy

Ripple and Noise

Dynamic Response

Overshoot

Turn-on Delay

Short Circuit Protection

Over Voltage Protection

OverTemperature Protection

Conditions/Description

Min

Nom

Max

±1

±2

±5

2.0

5% Vo

10 mS

Units

% pk-pk

% of Vout

20MHz Bandwidth. See Note 1

Output Deviation R/S : 1 A/uS

Settling Time Load : 25% ~ 75% full Load

Measured at 220VAC and full load

Auto Recovery

Latching. See individual models OVP levels

Internal Component Temperature

110

°C

General Specifications

Parameter

Isolation Voltage

Efficiency

Safety Agency Approvals

No load Power Dissipation

MTBF

Lifetime

Weight

Operating Temperature

Storage Temperature

Relative Humidity

Note 1.

Note 2.

Note 3.

Conditions/Description

Input to Output

See Note 2

Input to Chassis

See individual models

UL8750, EN61347-1, -2-13

Measured at 120VAC and 220VAC

MIL HDBK-217F, 110VAC input, 80% load, 25°C

220VAC input, 80% load, 45°C

Min

3750

1500

Nom

Max

Units

VAC

Hours

°C

%RH

94.0

1.5

584,000

74,000

1000

-35

-40

+70

+85

100

Non-condensing (operating)

Output connected in parallel with 0.1uF ceramic capacitor and 10uF electrolytic capacitor.

Primary to Secondary Isolation test not to be carried on power supply.

90-305VAC input voltage range available. Add Suffix “W” to part number e.g. LXV150-012SW

Europe/Asia

North America

Excelsys Technologies Ltd t: +353 21 4354716

Excelsys Technologies

27 Eastgate Drive

f: +353 21 4354864

Eastgate Business Park

e: sales@excelsys.com 519 Interstate 30, #309

Rockwall, TX 75087

Little Island, Cork, Ireland

USA

IRELAND

t: (972) 771 4544

f: (972) 421 1805

e: salesusa@excelsys.com
