9
8
7
6
5
4
3
2
1
0.80
A
B
Y
1. MATERIAL:
E
HOUSING: LIQUID CRYSTALLINE POLYMER, GLASS FILLED, UL94V-0, BLACK
0.635
TERMINAL: HIGH PERFORMANCE COPPER ALLOY
FINISHES: SEE PART NUMBER LEGEND IN SHEET 2
2. PRODUC SPECIFICATION: 781200001_PS
3. PACKAGING SPEICIFICATION: 781200001_PK
4. MATES WITH:87933, 200989, 201021, 201022, 201173
SEE VIEW A
5. PARTS CONFORMS TO CLASS "B" REQUIREMENT OF COSMETIC SPECIFICATION
PS-45499-002
6. MOLEX LOGO AND CAVITY LOCATED AS SHOWN.
7. NON-FUNCTIONAL CORING IS SUBJECTED TO CHANGES WITHOUT NOTICE.
8. THE ABOVE 10 CKT SHOWN IS FOR ILLUSTRATION ONLY.
E
x
3.43
1.27
1.00
1.27
TYP
0.635
D
0.46
TYP
⌖
0.20
Z
X Y
CKT SIZE
D
DIMENSION
A
B
2.75 1.27
4.02 2.54
5.29 3.81
6.56 5.08
7.83 6.35
9.10 7.62
10.37 8.89
11.64 10.16
12.91 11.43
14.18 12.70
15.45 13.97
4.51
C
⌓
0.15
4.59
B
W
4
6
8
10
12
14
16
18
20
22
24
C
VIEW A
1.27
TYP
B
B
2016/11/01
2016/11/17
2016/11/24
5.40
TYP
2.00
TYP
QUALITY THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
SYMBOLS
GENERAL
=
=
=
0
PRELIM. RELEASE
TOLERANCES
(UNLESS SPECIFIED)
ANGULAR TOL ±
3.0
°
MM
DRWN BY
DATE
NTS
0
0
0
0
0
0
0
4 PLACES
±
±
±
±
±
SCHEONG
CHK'D BY
DATE
2016/02/21
2016/07/17
DATE
109684
SCHEONG
GMENARLY
KHLIM
A
RECOMMENDED PCB LAYOUT
TOLERANCE
+0.05
(10 CKT SHOWN IS FOR ILLUSTRATION ONLY)
0.74
TYP
⌖
0.05
W
=
=
=
=
C
3 PLACES
2 PLACES
1 PLACE
0 PLACES
1.27MM PITCH SLIM-GRID
VERTICAL SMT RECEPTACLE
0.2
GMENARLY
APPR BY
A
PRODUCT CUSTOMER DRAWING
SERIES
MATERIAL NUMBER
CUSTOMER
KHLIM
DRAWING SIZE
2016/07/18
THIRD ANGLE PROJECTION
EC NO:
DRWN:
CHK'D:
APPR:
RELEASE STATUS
FORMAT: master-tb-prod-A3
REVISION: G
DATE: 2015/12/14
P1
RELEASE DATE
24.11.2016
10:21:14
=
A1
REV
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
78120
DOCUMENT NUMBER
SEE TABLE
GENERAL MARKET
DOC TYPE
DOC PART
SHEET NUMBER
A3
3
781200001
PSD
000
1 OF 2
9
8
7
6
5
4
2
1
9
CKT SIZE
8
ASSEMBLY P/N WITHOUT
KAPTON TAPE IN TUBE
78120-0407
78120-0408
78120-0409
78120-0607
78120-0608
78120-0609
78120-0807
78120-0808
78120-0809
78120-1007
78120-1008
78120-1009
78120-1207
78120-1208
78120-1209
78120-1407
78120-1408
78120-1409
78120-1607
78120-1608
78120-1609
78120-1807
78120-1808
78120-1809
78120-2007
78120-2008
78120-2009
78120-2207
78120-2208
78120-2209
78120-2407
78120-2408
78120-2409
7
ASSEMBLY P/N WITH KAPTON
TAPE IN TUBE (TOOLED)
78120-0417
78120-0418
78120-0419
78120-0617
78120-0618
78120-0619
78120-0817
78120-0818
78120-0819
78120-1017
78120-1018
78120-1019
78120-1217
78120-1218
78120-1219
78120-1417
78120-1418
78120-1419
78120-1617
78120-1618
78120-1619
78120-1817
78120-1818
78120-1819
78120-2017
78120-2018
78120-2019
78120-2217
78120-2218
78120-2219
78120-2417
78120-2418
78120-2419
6
ASSEMBLY P/N WITH KAPTON
TAPE IN T&R (NOT TOOLED)
78120-0427
78120-0428
78120-0429
78120-0627
78120-0628
78120-0629
78120-0827
78120-0828
78120-0829
78120-1027
78120-1028
78120-1029
78120-1227
78120-1228
78120-1229
78120-1427
78120-1428
78120-1429
78120-1627
78120-1628
78120-1629
78120-1827
78120-1828
78120-1829
78120-2027
78120-2028
78120-2029
78120-2227
78120-2228
78120-2229
78120-2427
78120-2428
78120-2429
5
4
3
2
1
4
E
6
E
8
10
12
D
14
D
16
MAXIMUM CKT SIZE
WITH KAPTON TAPE
18
20
C
22
C
24
B
ASSEMBLY
78120-X
X
X X
CKT SIZE
B
PRELIM. RELEASE
04 = 4 CKTS
.
.
24 = 24 CKTS
A
EC NO:
DRWN:
CHK'D:
APPR:
FINISHES
7 = 0.05um Au MIN. GOLD ON CONTACT AND 2.54um
MIN. MATTE TIN ON SOLDERTAIL OVER
1.27um MIN. NICKEL UNDERPLATE OVERALL
8 = 0.38um Au MIN. GOLD ON CONTACT AND 2.54um
MIN. MATTE TIN ON SOLDERTAIL OVER
1.27um MIN. NICKEL UNDERPLATE OVERALL
9 = 0.76um Au MIN. GOLD ON CONTACT AND 2.54um
MIN. MATTE TIN ON SOLDERTAIL OVER
1.27um MIN. NICKEL UNDERPLATE OVERALL
PACKAGING & PICK AND PLACE CAPABILITY
0 = NO KAPTON TAPE IN TUBE
1 = WITH KAPTON TAPE IN TUBE
2 = WITH KAPTON TAPE IN TAPE AND REEL
P1
RELEASE DATE
2016/11/01
2016/11/17
2016/11/24
QUALITY THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
SYMBOLS
GENERAL
=
=
=
=
=
=
=
C
0
0
0
0
0
0
0
0
TOLERANCES
(UNLESS SPECIFIED)
ANGULAR TOL ±
3.0
°
MM
DRWN BY
DATE
NTS
4 PLACES
±
±
±
±
±
SCHEONG
CHK'D BY
DATE
2016/02/21
2016/07/17
DATE
109684
SCHEONG
GMENARLY
KHLIM
3 PLACES
2 PLACES
1 PLACE
0 PLACES
1.27MM PITCH SLIM-GRID
VERTICAL SMT RECEPTACLE
0.2
GMENARLY
APPR BY
A
PRODUCT CUSTOMER DRAWING
SERIES
MATERIAL NUMBER
CUSTOMER
KHLIM
DRAWING SIZE
2016/07/18
THIRD ANGLE PROJECTION
RELEASE STATUS
FORMAT: master-tb-prod-A3
REVISION: G
DATE: 2015/12/14
24.11.2016
10:21:14
=
A1
REV
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
78120
DOCUMENT NUMBER
SEE TABLE
GENERAL MARKET
DOC TYPE
DOC PART
SHEET NUMBER
A3
3
781200001
PSD
000
2 OF 2
9
8
7
6
5
4
2
1
