RR series, high-precision metal
film chip resistors
Excellent in resistance tolerance, thermal coefficient of resistance, high-frequency
characteristics, current-noise-free characteristics, and minimized third harmonic
distortion.
Our SMD components contribute to lead-free composition of electronics products.
NEW
RR0306, RR0510, RR0816, and RR1220 series provide higher maximum
limits of resistance values.
SPECIFICATIONS
Mechanical
Dimension
(mm)
L
W
P
T
RR0306
(0201)
0.60
0.30
0.12
0.23
0.05
0.05
0.05
0.03
RR0510
(0402)
1.00
0.50
0.20
0.35
0.05
0.05
0.10
0.05
RR0816
(0603)
1.60
0.80
0.30
0.40
0.20
0.20
0.20
0.10
RR1220
(0805)
2.00
1.25
0.40
0.40
0.20
0.20
0.20
0.10
RR1632
(1206)
3.20
1.60
0.50
0.40
0.20
0.20
0.20
0.10
RR2632
(1210)
3.20
2.60
0.50
0.40
0.20
0.20
0.20
0.10
W
P
L
Equivalent circuit
T
Electrical
Type
Power
Resistance Tolerance
(code)
Resistance Range
(ohm)
Temperature Coefficient
of Resistance ppm C(code)
Resistance Value
Maximum Operating Voltage
Package
RR0306
1/20W
1.0% 0.5% 1%(F)
(F)
(D)
NEW
RR0510
1/16W
0.5%(D) 1%(F)
NEW
RR0816
1/16W
0.5%(D) 1%(F)
NEW
RR1220
1/10W
0.5%(D) 1%(F)
NEW
RR1632
1/8W
0.5%
(D)
RR2632
1/4W
10
30
33
27
10 100 102 10 100 365K 10 100 1.02 10 49.9 51 1M 10 49.9 51 2M
22K 100K 97.6 100K 330K 97.6 360K 1.3M 97.6 1M 3.6M
200 100 25
(S) (R) (P)
200 50
(S) (Q)
25
(P)
200 50
(S) (Q)
25
(P)
200
(S)
50
(Q)
25
(P)
50
(Q)
25
(P)
100 25
(R) (P)
E 24
15V
E 24/E 96
25V
10,000pcs/reel
E 24/E 96
75V
5,000pcs/reel
E 24/E 96
100V
5,000pcs/reel
E 24/E 96
150V
5,000pcs/reel
E 24/E 96
200V
1,000•
5,000pcs/reel
5,000pcs/reel
Contact us also for RL0816-JMP jumper resistor whose dimensions are the same as those of RR0816.
NEW
RR0816 with 1/10W power consumption, RR1220 with 1/8W power consumption, and RR1632 with 1/4W power
consumption are available to meet your needs.
PART NUMBER
RR 0816 P - 102 - D
Resistance Tolerance
Resistance (RR1632 and RR2632 are expressed
in four-digit figures.)
Temperature Coefficient of Resistance
Dimensions
Part Code
