IS61LPS409618B, IS61LPS204836B, IS61LPS204832B, IS64LPS204836B,
IS61VPS/VVPS409618B, IS61VPS/VVPS204836B
2M x 36, 2M x 32, 4M x 18
72 Mb SYNCHRONOUS PIPELINED,
SINgLE CYCLE DESELECT STATIC RAM
FEATURES
• Internal self-timed write cycle
• Individual Byte Write Control and Global Write
• Clock controlled, registered address, data and
control
• Burst sequence control using MODE input
• Three chip enable option for simple depth ex-
pansion and address pipelining
• Common data inputs and data outputs
• Auto Power-down during deselect
• Single cycle deselect
• Snooze MODE for reduced-power standby
• JTAG Boundary Scan for PBGA package
• Power Supply
LPS: V
dd
3.3V (+ 5%),
V
ddq
3.3V/2.5V (+ 5%)
VPS: V
dd
2.5V (+ 5%),
V
ddq
2.5V (+ 5%)
VVPS: V
dd
1.8V (+ 5%),
V
ddq
1.8V (+ 5%)
• JEDEC 100-Pin TQFP, 119-ball PBGA, and
165-ball PBGA packages
• Lead-free available
OCTOBER 2017
DESCRIPTION
The 72Mb product family features high-speed, low-power
synchronous static RAMs designed to provide burstable,
high-performance memory for communication and net-
working applications. The IS61LPS/VPS204836B and
IS64LPS204836B are organized as 2,096,952 words by
36 bits. The IS61LPS204832B is organized as 2,096,952
words by 32 bits. The IS61LPS/VPS409618B is organized
as 4,193,904 words by 18 bits. Fabricated with
ISSI
's
advanced CMOS technology, the device integrates a
2-bit burst counter, high-speed SRAM core, and high-
drive capability outputs into a single monolithic circuit. All
synchronous inputs pass through registers controlled by
a positive-edge-triggered single clock input.
Write cycles are internally self-timed and are initiated by
the rising edge of the clock input. Write cycles can be
one to four bytes wide as controlled by the write control
inputs.
Separate byte enables allow individual bytes to be written.
The byte write operation is performed by using the byte
write enable (BWE) input combined with one or more
individual byte write signals (BWx). In addition, Global
Write (GW) is available for writing all bytes at one time,
regardless of the byte write controls.
Bursts can be initiated with either ADSP (Address Status
Processor) or ADSC (Address Status Cache Controller)
input pins. Subsequent burst addresses can be gener-
ated internally and controlled by the ADV (burst address
advance) input pin.
The mode pin is used to select the burst sequence or-
der, Linear burst is achieved when this pin is tied LOW.
Interleave burst is achieved when this pin is tied HIGH
or left floating.
250
2.8
4
250
200
3.1
5
200
166
3.8
6
166
Units
ns
ns
MHz
FAST ACCESS TIME
Symbol
t
kq
t
kc
Parameter
Clock Access Time
Cycle Time
Frequency
Copyright © 2017 Integrated Silicon Solution, Inc. All rights reserved. ISSI reserves the right to make changes to this specification and its products at any time without notice. ISSI assumes no
liability arising out of the application or use of any information, products or services described herein. Customers are advised to obtain the latest version of this device specification before relying on
any published information and before placing orders for products.
Integrated Silicon Solution, Inc. does not recommend the use of any of its products in life support applications where the failure or malfunction of the product can reasonably be expected to cause
failure of the life support system or to significantly affect its safety or effectiveness. Products are not authorized for use in such applications unless Integrated Silicon Solution, Inc. receives written
assurance to its satisfaction, that:
a.) the risk of injury or damage has been minimized;
b.) the user assume all such risks; and
c.) potential liability of Integrated Silicon Solution, Inc is adequately protected under the circumstances
Integrated Silicon Solution, Inc. — www.issi.com —
1-800-379-4774
Rev. D
10/23/2017
1
IS61LPS409618B, IS61LPS204836B, IS61LPS204832B, IS64LPS204836B,
IS61VPS/VVPS409618B, IS61VPS/VVPS204836B
119 BGA PACKAGE PIN CONFIGURATION-
2M
x
36 (TOP VIEW)
1
A
B
C
D
E
F
g
H
J
K
L
M
N
P
R
T
U
V
DDQ
NC
NC
DQc
DQc
V
DDQ
DQc
DQc
V
DDQ
DQd
DQd
V
DDQ
DQd
DQd
NC
NC
V
DDQ
2
A
A
A
DQPc
DQc
DQc
DQc
DQc
V
DD
DQd
DQd
DQd
DQd
DQPd
A
A
TMS
3
A
A
A
Vss
Vss
Vss
BWc
Vss
NC
Vss
BWd
Vss
Vss
Vss
MODE
A
TDI
4
ADSP
ADSC
V
DD
NC
CE
OE
ADV
GW
V
DD
CLK
NC
BWE
A
1
*
A
0
*
V
DD
A
TCK
5
A
A
A
Vss
Vss
Vss
BWb
Vss
NC
Vss
BWa
Vss
Vss
Vss
NC
A
TDO
6
A
A
A
DQPb
DQb
DQb
DQb
DQb
V
DD
DQa
DQa
DQa
DQa
DQPa
A
A
NC
7
V
DDQ
NC
NC
DQb
DQb
V
DDQ
DQb
DQb
V
DDQ
DQa
DQa
V
DDQ
DQa
DQa
NC
ZZ
V
DDQ
Note:
* A
0
and A
1
are the two least significant bits (LSB) of the address field and set the internal burst counter if burst is desired.
PIN DESCRIPTIONS
Symbol
A
A0, A1
ADV
ADSP
ADSC
GW
CLK
CE, CE2
BWa-BWd
BWE
Pin Name
Synchronous Address Inputs
Synchronous Burst Address Inputs
Synchronous Burst Address
Advance
Synchronous Address Status Processor
Synchronous Address Status Controller
Synchronous Global Write Enable
Synchronous Clock
Synchronous Chip Select
Synchronous Byte Write Controls
Synchronous Byte Write Enable
Symbol
OE
ZZ
MODE
TCK, TDO
TMS, TDI
NC
DQa-DQd
DQPa-DQPd
V
dd
V
ddq
Vss
No Connect
Synchronous Data Inputs/Outputs
Synchronous Parity Data
Inputs/Outputs
Power Supply
I/O Power Supply
Ground
Pin Name
Asynchronous Output Enable
Asynchronous Power Sleep Mode
Burst Sequence Selection
JTAG Pins
4
Integrated Silicon Solution, Inc. — www.issi.com —
1-800-379-4774
Rev. D
10/23/2017
IS61LPS409618B, IS61LPS204836B, IS61LPS204832B, IS64LPS204836B,
IS61VPS/VVPS409618B, IS61VPS/VVPS204836B
119 BGA PACKAGE PIN CONFIGURATION
4M
x
18 (TOP VIEW)
1
A
B
C
D
E
F
g
H
J
K
L
M
N
P
R
T
U
V
DDQ
NC
NC
DQb
NC
V
DDQ
NC
DQb
V
DDQ
NC
DQb
V
DDQ
DQb
NC
NC
A
V
DDQ
2
A
A
A
NC
DQb
NC
DQb
NC
V
DD
DQb
NC
DQb
NC
DQPb
A
A
TMS
3
A
A
A
Vss
Vss
Vss
BWb
Vss
NC
Vss
Vss
Vss
Vss
Vss
MODE
A
TDI
4
ADSP
ADSC
V
DD
NC
CE
OE
ADV
GW
V
DD
CLK
NC
BWE
A
1
*
A
0
*
V
DD
A
TCK
5
A
A
A
Vss
Vss
Vss
Vss
Vss
NC
Vss
BWa
Vss
Vss
Vss
NC
A
TDO
6
A
A
A
DQPa
NC
DQa
NC
DQa
V
DD
NC
DQa
NC
DQa
NC
A
A
NC
7
V
DDQ
NC
NC
NC
DQa
V
DDQ
DQa
NC
V
DDQ
DQa
NC
V
DDQ
NC
DQa
NC
ZZ
V
DDQ
Note:
* A
0
and A
1
are the two least significant bits (LSB) of the address field and set the internal burst counter if burst is desired.
PIN DESCRIPTIONS
Symbol
A
A0, A1
ADV
ADSP
ADSC
GW
CLK
CE, CE2
BWa-BWb
BWE
Pin Name
Synchronous Address Inputs
Synchronous Burst Address Inputs
Synchronous Burst Address
Advance
Synchronous Address Status Processor
Synchronous Address Status Controller
Synchronous Global Write Enable
Synchronous Clock
Synchronous Chip Select
Synchronous Byte Write Controls
Synchronous Byte Write Enable
Symbol
OE
ZZ
MODE
TCK, TDO
TMS, TDI
NC
DQa-DQb
DQPa-DQPb
V
dd
V
ddq
Vss
No Connect
Synchronous Data Inputs/Outputs
Synchronous Parity Data
Inputs/Outputs
Power Supply
I/O Power Supply
Ground
Pin Name
Asynchronous Output Enable
Asynchronous Power Sleep Mode
Burst Sequence Selection
JTAG Pins
Integrated Silicon Solution, Inc. — www.issi.com —
1-800-379-4774
Rev. D
10/23/2017
5
