KTC811E-GR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> KTC811E-GR

KTC811E-GR: DescriptionSmall Signal Bipolar Transistor, 0.15A I(C), 50V V(BR)CEO, 2-Element, NPN, Silicon, TES6, 6 PIN; CategoryDiscrete semiconductor The transistor; File Size694KB，3 Pages; ManufacturerKEC; Websitehttp://www.keccorp.com/

Download Datasheet Parametric Compare View All

KTC811E-GR Overview

Small Signal Bipolar Transistor, 0.15A I(C), 50V V(BR)CEO, 2-Element, NPN, Silicon, TES6, 6 PIN

KTC811E-GR Parametric

Parameter Name	Attribute value
Maker	KEC
package instruction	SMALL OUTLINE, R-PDSO-F6
Contacts	6
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum collector current (IC)	0.15 A
Collector-emitter maximum voltage	50 V
Configuration	SEPARATE, 2 ELEMENTS
Minimum DC current gain (hFE)	200
JESD-30 code	R-PDSO-F6
Number of components	2
Number of terminals	6
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	NPN
Certification status	Not Qualified
surface mount	YES
Terminal form	FLAT
Terminal location	DUAL
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	80 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

SEMICONDUCTOR

TECHNICAL DATA

GENERAL PURPOSE APPLICATION.

SWITCHING APPLICATION.

FEATURES

・A

super-minimold package houses 2 transistor.

・Excellent

temperature response between these 2 transistor.

・High

pairing property in h

・The

follwing characteristics are common for Q

, Q

KTC811E

EPITAXIAL PLANAR NPN TRANSISTOR

MAXIMUM RATING (Ta=25℃)

CHARACTERISTIC

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Collector Current

Base Current

Collector Power Dissipation

Junction Temperature

Storage Temperature Range

* Total Rating

SYMBOL

CBO

CEO

EBO

stg

RATING

150

200

150

-55½150

UNIT

℃

EQUIVALENT CIRCUIT (TOP VIEW)

ELECTRICAL CHARACTERISTICS (Ta=25℃)

CHARACTERISTIC

Collector Cut-off Current

Emitter Cut-off Current

DC Current Gain

Collector-Emitter Saturation Voltage

Transition Frequency

Collector Output Capacitance

Noise Figure

SYMBOL

CBO

EBO

(Note)

CE(sat)

TEST CONDITION

=60V, I

=5V, I

=6V, I

=2㎃

=100㎃, I

=10㎃

=10V, I

=1㎃

=10V, I

=0, f=1㎒

=6V, I

=0.1㎃, f=1㎑, Rg=10㏀

MIN.

120

TYP.

0.1

1.0

MAX.

0.1

400

0.3

3.5

㎒

㎊

㏈

UNIT.

㎂

Note : h

Classification Y(4):120½240, GR(6):200½400

Marking

2014. 3. 31

Revision No : 2

1/3
