390238-4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 390238-4

390238-4: DescriptionSIMM/DIMM SOCKET,168 CONTACTS,2; CategoryThe connector The connector; File Size107KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

390238-4 Overview

SIMM/DIMM SOCKET,168 CONTACTS,2

390238-4 Parametric

Parameter Name	Attribute value
Objectid	303466420
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	TRAY PACKAGING
Board mount options	COMPLIANT BOARDLOCK
body width	0.301 inch
subject depth	0.906 inch
body length	5.787 inch
Body/casing type	RECEPTACLE
Connector type	CARD EDGE CONNECTOR
Contact to complete cooperation	AU ON NI
Contact completed and terminated	TIN/LEAD OVER NICKEL
Contact material	PHOSPHOR BRONZE
Contact resistance	20 mΩ
Contact style	BELLOWED TYPE
Dielectric withstand voltage	500VAC V
Durability	25 Cycles
maximum insertion force	.8618 N
Insulation resistance	1000000 Ω
Insulator color	BLACK
insulator material	NYLON
Manufacturer's serial number	390238
Plug contact pitch	0.039 inch
Installation option 1	LATCH & EJECT
Installation option 2	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	4
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
PCB contact pattern	STAGGERED
PCB contact row spacing	0.063 mm
Plating thickness	15u inch
polarization key	POLARIZED KEY
Rated current (signal)	0.5 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.11 inch
Terminal pitch	2.0066 mm
Termination type	SOLDER
Total number of contacts	168
Evacuation force-minimum value	.3614 N

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Socket/C ard Products

Product Feature Selector

> Product Details

390238-4 Product Details

Live Product Chat

Memory Sockets

Not re vie we d for R oHS C om plia nce

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

390238-4

T E I nternal N umber: 3 9 0 2 3 8 - 4

Product Highlights:

Rambus RIMM

Gold (15) C ontact Mating Area Plating Material

Number of Positions = 168

DRAM Type = Direct RDRAM

DRAM Voltage = 2.5 V

View all Features

Obsolete

C ontact Product Information

C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

PERSONAL SYSTEMS PRODUC TS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

Rambus In-Line Memory Module (RIMM) Sockets

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Rambus RIMM

Number of Positions

= 168

DRAM Type

= Direct RDRAM

PC B Mount Style = Through Hole

Module Orientation

= Vertical

PC B Retention Feature = Yes

Profile = Standard

Mechanical Attachment:

C enter Retention Hole Diameter (mm [in])

= 2.44 [0.096]

Electrical Characteristics:

DRAM Voltage

= 2.5 V

Termination Related Features:

Termination Post Length (mm [in])

= 2.79 [0.110]

Solder Tail C ontact Plating = Tin-Lead over Nickel

Body Related Features:

C enterline (mm [in])

= 1.00 [0.039]

Number of Rows

= Dual

Ejector Type = Locking

Ejector Location

= Both Ends

Number of Bays

= 2

Number of Keys

= 2

PC B Retention Method = Boardlock(s)

Mount Type = Printed C ircuit Board

Contact Related Features:

C ontact Mating Area Plating Material = Gold (15)

C ontact Base Material = Phosphor Bronze

Retention Post Material = Stainless Steel

Housing Related Features:

Housing Material = High Temperature Nylon

Housing C olor = Black

Housing Flammability Rating = UL 94V-0

Configuration Related Features:

Insertion Style

= Direct Insert

Industry Standards:

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Operation/Application:

Application Type = RIMM

Packaging Related Features:

Packaging Method = Tray

Other:

Brand = AMP

Additional Information:

Product Line Information
