5.0V/3.0V Plastic HCMOS/TTL Oscillator
Model: FSOlF Series
RoHS compliant / Pb Free
Rev. 9/18/2006
FEATURES
•
•
•
•
•
5.0V / 3.3V Operation
Discontinued
learn more about:
Part Marking Identification
Tape and Reel Specification
Mechanical Specification
internet required
http://www.foxonline.com/need_a_sample.htm
HCMOS/TTL Output
Tri-State Enable/Disable
Extended Temperature Range
Tape and Reel (1,000 pcs. STD)
• PART nUMbER SElEcTiOn
Learn More - Internet Required
Part Number
259LF-Freq-xxxxx
547LF-Freq-xxxxx
432LF-Freq-xxxxx
433LF-Freq-xxxxx
543LF-Freq-xxxxx
434LF-Freq-xxxxx
Model
Number
FSO-2LF
3
FSO-2RLF
FSO-25LF
FSO-3LF
3
FSO-3RLF
FSO-35LF
Frequency
Operating
V
dd
(V) Frequency
1
Range (MHz)
Stability
Temperature (ºC)
5.0 ± 0.5 ±100PPM
-20 ~ +70 1.000 ~ 66.6667
±100PPM
-40 ~ +85 1.000 ~ 66.6667
±50PPM
-20 ~ +70 1.000 ~ 66.6667
3.3 ± 0.3 ±100PPM
-20 ~ +70 1.000 ~ 66.6667
±100PPM
-40 ~ +85 1.000 ~ 66.6667
±50PPM
-20 ~ +70 1.000 ~ 66.6667
• ElEcTRicAl cHARAcTERiSTicS
PARAMETERS
Frequency Range (F
o
)
Input Current
(I
dd
)
1.000 ~ 30.000 MHz
30.000+ ~ 66.6667 MHz
Output Symmetry (50% V
dd
)
Rise Time (20% ~ 80% V
dd
) (T
r
)
1.000 ~ 30.000 MHz
30.000+ ~ 66.6667 MHz
Fall Time (80% ~ 20% V
dd
) (T
f
)
1.000 ~ 30.000 MHz
30.000+ ~ 66.6667 MHz
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
(TTL)
(HCMOS)
Start-up Time
(T
s
)
1.000 ~ 30.000 MHz
30.000+ ~ 66.6667 MHz
Enable/Disable Time
2
1
FSO-2LF Series FSO-3LF Series
MAX
(unless otherwise noted)
1.000 ~ 66.6667 MHz
23mA
35mA
9mA
20mA
40% ~ 60%
6nS
6nS
6nS
6nS
0.4V
2.9V Min
4mA Min
-4mA Min
---
30pF
4mS
10mS
100nS
8nS
7nS
8nS
7nS
0.4V
4.6V Min
16mA Min
-16mA Min
10TTL
50pF
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, aging, and load
change.
2
An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
3
The FSO-2LF and FSO-3LF models will also operate over -40ºC ~ +85ºC, but with a
stability of ±200 PPM.
Note: A 0.01µF bypass capacitor should be placed between VDD (Pin 4) and GND (Pin 2) to
minimize power supply line noise.
All specifications subject to change without notice.
All dimensions are in millimeters.
• EnAblE / DiSAblE FUncTiOn
INH (Pin 1)
OUTPUT (Pin 3)
OPEN
2
ACTIVE
'1' Level V
ih
≥
2.4 V
ACTIVE
'0' Level V
il
≤
0.6 V
High Z
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
