Optical Isolator
Features and Benefits
Wide Optical Wavelength and Temperature Range
Low Insertion Loss
High Isolation
Epoxy Free in Optical Path
Ultra Low PDL and PMD
Corning offers single-stage and dual-stage optical isolators
which minimize back reflection and back scattering in
the reverse direction at any state of polarization. The
Polarization Insensitive Isolator (PII) is a low-cost model
with excellent performance, including low insertion loss,
high isolation, high return loss, and low PDL and PMD. It is
available in both C and L band.
Standards
RoHS
Free of hazardous
substances according to
RoHS2011/65/EU
Product is qualified to
Telcordia GR-1209-CORE and
GR-1221-CORE
Design and Test Criteria
Optical Isolator
Spec Sheet CAH-144_AEN
Page 1 | Revision date 2016-12-13
Optical Isolator
Specifications – Optical Isolator
Parameters
Ultra
Center Wavelength (lc)
Isolation (lc ± 15 nm, 23°C, All SOP), Minimum
Isolation (lc ± 15 nm, 0-70°C, All SOP), Minimum
Insertion Loss (lc, 23°C, All SOP), Typical
Insertion Loss (lc ± 20 nm, 0-70°C, All SOP), Maximum
PDL, Maximum
PMD, Maximum
Return Loss (Input/Output), Minimum
Power Handling
Operating Temperature
Storage Temperature
30 dB
21 dB
0.30 dB
0.40 dB
0.05 dB
0.30 ps
Single-Stage
Premium
1310, 1550, or 1590 nm
30 dB
21 dB
0.35 dB
0.50 dB
0.05 dB
0.30 ps
60/60 dB
500 mW
0°C to +70°C
-40°C to +85°C
30 dB
20 dB
0.40 dB
0.60 dB
0.10 dB
0.30 ps
Standard
Shipping Package
Packaging Dimensions
(F) 5.5 mm x (L) 45* mm Including boots
Fiber Type
Corning® MF-28e®; 250 µm Fiber
Pigtail Length
1 m (Standard)
Note:
*250 µm bare fiber; our 900 µm buffer solution is at 49 mm length
Spec Sheet CAH-144_AEN
Page 2 | Revision date 2016-12-13
Optical Isolator
Specifications – Optical Isolator
Parameters
Single-Stage PMD
Compensated
Ultra
Center Wavelength (lc)
Peak Isolation, Minimum
Isolation (lc ± 15 nm, 23°C, All SOP), Minimum
Isolation (lc ± 30 nm, 23°C, All SOP), Minimum
Isolation (lc ± 15 nm, 0-70°C, All SOP), Minimum
Insertion Loss (lc, 23°C, All SOP), Typical
Insertion Loss (lc ± 20 nm, 0-70°C, All SOP),
Maximum
Insertion Loss (lc ± 30 nm, 0-70°C, All SOP),
Maximum
PDL, Maximum
PMD, Maximum
Return Loss (Input/Output), Minimum
Power Handling, Maximum
Operating Temperature
Storage Temperature
-
21 dB
0.30 dB
0.50 dB
-
0.05 dB
0.02 ps
60/60 dB
-
Premium
-
30 dB
-
21 dB
0.35 dB
0.50 dB
-
0.05 dB
0.05 ps
60/60 dB
500 mW
0°C to +70°C
-40°C to +85°C
-
20 dB
0.40 dB
0.60 dB
-
0.10 dB
0.05 ps
60/55 dB
Standard
-
Ultra
60 dB
55 dB
48 dB
42 dB
0.40 dB
0.55 dB
0.60 dB
0.05 dB
0.05 ps
60/60 dB
1310, 1550, 1590 nm
Dual-Stage PMD
Compensated
Premium
58 dB
-
46 dB
38 dB
0.40 dB
0.55 dB
0.60 dB
0.05 dB
0.05 ps
60/55 dB
500 mW
0°C to +70°C
-40°C to +85°C
Standard
55 dB
-
45 dB
34 dB
0.60 dB
0.70 dB
0.80 dB
0.10 dB
0.07 ps
60/55 dB
1310, 1550, 1590 nm
Ordering Information
Optical Isolator
I S
1
Select Type
1
- 1
-
2
1: Standard
2: Premium
3: Ultra
3
4
5
5
6
6
Select Customization
000: Running number
used for special types or
custom made
1: Single-Stage
2: PMD Compensated
Single-Stage
3: PMD Compensated
Dual-Stage
3
Select Grade
4
Select Fiber Type
2
Select Wavelenth
31: 1310 nm
55: 1550 nm
59: 1590 nm
0: 250 µm Bare Fiber
1: 900 µm Loose Tube
2: 900 µm Tight Fiber
Select Connector*
A: None
L : LC/PC
P: FC/PC
Q: FC/APC
S: SC/PC
T: SC/APC
U: MU/PC
These part numbers are specific to Corning Optical Communications OEM
Solutions Business Unit. Please contact OEM sales at +1-408-736-6900 or
oemsales@corning.com and visit www.corning.com/opcomm/oem for
sales support.
Corning Optical Communications LLC • PO Box 489 • Hickory, NC 28603-0489 USA
800-743-2675 • FAX: 828-325-5060 • International: +1-408-736-6900 • www.corning.com/opcomm/oem • Email: oemsales@corning.com
Corning Optical Communications reserves the right to improve, enhance, and modify the features and specifications of Corning Optical Communications products
without prior notification. A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks. All
other trademarks are the properties of their respective owners. Corning Optical Communications is ISO 9001 certified.
© 2016 Corning Optical Communications. All rights reserved.
Spec Sheet CAH-144_AEN
Page 3 | Revision date 2016-12-13
