390171-4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 390171-4

390171-4: DescriptionCONNECTOR, 168 CONTACT(S), FEMALE, RIGHT ANGLE SINGLE PART CARD EDGE CONN, SOLDER, SOCKET; CategoryThe connector The connector; File Size106KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

390171-4 Overview

CONNECTOR, 168 CONTACT(S), FEMALE, RIGHT ANGLE SINGLE PART CARD EDGE CONN, SOLDER, SOCKET

390171-4 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	unknown
Other features	LOW PROFILE
Body/casing type	SOCKET
Connector type	CARD EDGE CONNECTOR
Contact to complete cooperation	GOLD
Contact completed and terminated	TIN LEAD OVER NICKEL
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e0
MIL compliance	NO
Manufacturer's serial number	390171
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	1.27 mm
Termination type	SOLDER
Total number of contacts	168
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Socket/C ard Products

Product Feature Selector

> Product Details

390171-4 Product Details

Live Product Chat

Memory Sockets

Not EU R oHS or ELV C om plia nt

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

390171-4

T E I nternal N umber: 3 9 0 1 7 1 - 4

Product Highlights:

DIMM

Gold C ontact Mating Area Plating Material

Number of Positions = 168

DRAM Type = Standard

DRAM Voltage = 3.3 V

View all Features

Obsolete

C ontact Product Information

C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

Right-Angle DIMM II 168-Position Sockets

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= DIMM

Number of Positions

= 168

DRAM Type

= Standard

PC B Mount Style = Through Hole

Module Orientation

= Right Angle

PC B Retention Feature = Yes

Profile = Low

Mechanical Attachment:

C enter Retention Hole Diameter (mm [in])

= 2.40 [0.094]

Electrical Characteristics:

DRAM Voltage

= 3.3 V

Termination Related Features:

Termination Post Length (mm [in])

= 2.83 [0.111]

Solder Tail C ontact Plating = Tin-Lead over Nickel

Body Related Features:

Row-to-Row Spacing (mm [in])

= 1.90 [0.075]

C enterline (mm [in])

= 1.27 [0.050]

Number of Rows

= Dual

Ejector Type = Locking

Ejector Location

= Both Ends

C enter Post = With

Number of Keys

= 2

PC B Retention Method = Boardlock(s)

Mount Type = Printed C ircuit Board

Module Key Type = Key1= Offset Left / Key2= C enter

Contact Related Features:

C ontact Mating Area Plating Material = Gold

C ontact Base Material = Phosphor Bronze

Retention Post(s) Location

= C enter

Housing Related Features:

Housing Material = High Temperature Nylon

Housing C olor = Black

Housing Flammability Rating = UL 94V-0

Configuration Related Features:

Insertion Style

= Direct Insert

C enter Key (mm [in]) = C enter

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Wave solder capable to 240?C

Packaging Related Features:

Packaging Method = Tray

Other:

Brand = AMP

Additional Information:

Product Line Information
