ECS-240-20-20BM-CY-TR datasheet, PDF

Datasheet> All Categories > Passive components> Crystal/resonator> ECS-240-20-20BM-CY-TR

ECS-240-20-20BM-CY-TR: DescriptionParallel - Fundamental Quartz Crystal,; CategoryPassive components Crystal/resonator; File Size358KB，2 Pages; ManufacturerECS; Websitehttp://www.ecsxtal.com/; Environmental Compliance

Download Datasheet Parametric View All

ECS-240-20-20BM-CY-TR Overview

Parallel - Fundamental Quartz Crystal,

ECS-240-20-20BM-CY-TR Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	7197502113
package instruction	SMD, 4 PIN
Reach Compliance Code	compliant
YTEOL	6.88
Ageing	5 PPM/FIRST YEAR
Crystal/Resonator Type	PARALLEL - FUNDAMENTAL
Drive level	100 µW
frequency stability	0.005%
frequency tolerance	10 ppm
JESD-609 code	e4
load capacitance	20 pF
Installation features	SURFACE MOUNT
Nominal operating frequency	24 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
physical size	7.0mm x 5.0mm x 1.3mm
Series resistance	40 Ω
surface mount	YES
Terminal surface	Gold (Au)

Preview

Download Datasheet

View All

CSM-8M

SMD CRYSTAL

The CSM-8M is a miniature SMD Crystal with a 7.0 x 5.0 mm

footprint. This seam welded metal lid/ceramic package crystal is

ideal for PCMIA ethernet applications.

CSM-8M SMD CRYSTAL

Request a Sample

OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS

PARAMETERS

Frequency

Mode of Oscillation

Frequency Tolerance*

Frequency Stability*

Shunt Capacitance

Load Capacitance

Drive Level

Operating Temperature*

Storage Temperature

Aging (First Year)

Fundamental

@ +25°C

-10 ~ +70°C

CONDITIONS

MIN

CSM-8M

TYP

MAX

UNITS

42.000

± 30

± 50

MHz

ppm

μW

°C

ppm

6.000

Specify in P/N

opr

stg

@ +25°C ±3°C

Frequency (MHz)

6.000 ~ 7.999

8.000 ~ 15.999

16.000 ~ 42.000

-10

-55

•

Compact and Low Profile

RoHS Compliant

MSL: 1

Lead Finish: Au

Series

100

+70

+125

±5

DIMENSIONS (mm)

ESR Ω Max.

Pad Connections

In/Out

Gnd

Out/In

Gnd

Figure 1)

Top, Side, and Bottom

Crystal is symmetrical, pad 1 & 3 are interchangeable.

Chamfer on the bottom pad has no electrical

significance.

Figure 2)

Suggested land

pattern

PART NUMBERING GUIDE: Example ECS-200-20-20BM-TR

ECS - FREQUENCY ABBREVIATION

LOAD

CAPACITANCE

20 = 20 pF

S = Series

PACKAGE

Tolerance

20BM =

CSM-8M

Blank = Std

A = ± 25

ppm

J = ± 20

ppm

R = ± 15

ppm

C = ± 10

ppm

AVAILABLE OPTIONS

Stability

Blank= Std

D= ±100 ppm

E = ± 50 ppm

G = ± 30 ppm

H = ± 25 ppm

T = ± 20 ppm

†

W = ±15 ppm

†

K = ± 10 ppm

†

PACKAGING

Temp Range

Blank= Std

L = -10 ~ +70°C

M = -20 ~ +70°C

Y = -30 ~ +85°C

N = -40 ~ +85°C

P = -40 ~ +105°C

S = -40 ~ +125°C

U = -55 ~ +125°C

TR =

Tape

& Reel

1K/Reel

ECS

200 = 20.000 MHz

See P/N Guide

* Specify available options in P/N.

†

Contact ECS for availability over extended temp range.

Rev.2017

15351 West 109

Street

Lenexa, KS 66219

Phone: 913.782.7787

Fax: 913.782.6991

www.ecsxtal.com
