ADSL LINE TRANSFORMERS
For GlobespanVirata CO Chipsets
Approved by GlobespanVirata for use in Annex A
and Annex C, Central Office applications
Small footprint minimizes board space
Excellent THD performance
Designed to meet UL1950 and EN60950
supplementary insulation requirements for
working voltages up to 250 Vrms
Electrical Specifications @ 25°C — Operating Temperature -40°C to +85°C
Part
Number
1
BX2373JB
Surface
Mount
Leads
J-Lead
Chipset(s)
ADSL CO
Termination
Active
Turns Ratio
Line : Chip
(±2%)
1.15CS:1CS
Inductance
@10 kHz,100 mV
(1-4) with (2-3) shorted
474 µH ±10%
Leakage Inductance
@ 100 kHz, 0.1 Vrms
Line Side
10 µH MAX
DC Resistance
Line Side
2
(1-4) with (2-3) shorted
Chip Side
2.5
Ω
MAX
2.2
Ω
MAX
1.5
Ω
MAX
2.2
Ω
MAX
1.7
Ω
MAX
1.5
Ω
MAX
BX2373WA
Gull-Wing
BX2369JB
J-Lead
Titanium™ Fourte,
Titanium™ Fourte RT,
and Titanium™ G16
BX2369WA
Gull-Wing
B2414JB
B2414WA
J-Lead
Gull-Wing
Jupiter™
Passive
1.41CS:1CS
474 µH ±6%
10 µH MAX
Active
0.95CS:1CS
750 µH ±7%
5 µH MAX
Additional Electrical Specifications
Part
Number
1
BX2373JB
BX2373WA
BX2369JB
BX2369WA
B2414JB
B2414WA
Longitudinal Balance
(from 20 kHz to 1.0 MHz)
≤
-45 dB
≤
-45 dB
≤
-45 dB (to 1.1 MHz)
THD @ 150 kH
(100
Ω)
≤
-85 dB (@ 12 Vpp)
≤
-85 dB (@ 15 Vpp)
≤
-85 dB (@ 12 Vpp)
Insertion Loss at 100
Ω
(dB)
≤
0.50 (150 kHz to 300 kHz)
≤
1.00 (1.0 MHz)
≤
1.00 (150 kHz to 1.0 MHz)
≤
0.40 (150 kHz to 300 kHz)
≤
0.75 (1.0 MHz)
Interwinding Capacitance
(@ 100 kHz, 0.1 Vrms)
≤
50 pF
≤
50 pF
≤
50 pF
Isolation Voltage
(60 sec)
1500 Vrms
1500 Vrms
1500 Vrms
NOTES:
1. Transformers are shipped in trays unless Tape & Reel packaging is specified by adding the suffix
“T”
to the part number (i.e. BX2373JBT).
2. Chip Side DCR Measurements:
Schematic A
= (8-5) with (6-7) shorted;
Schematic B
= (8-6) with (5-7) shorted.
Schematics
BX2373WA/BX2369WA/B2414WA
BX2373JB/BX2369JB/B2414JB
1
LINE
3
2
4
8
6
7
5
CHIP
LINE
1
3
2
4
8
5
7
6
CHIP
Schematic A
Schematic B
US 858 674 8100
•
UK 44 1483 401 700
•
France 33 3 84 35 04 04
•
Singapore 65 287 8998
•
Taiwan 886 2 2698 0228
•
Hong Kong 852 2788 6588
•
http://www.pulseeng.com
B991.B (4/02)
ADSL LINE TRANSFORMERS
For GlobespanVirata CO Chipsets
Mechanicals
BX2373JB/BX2369JB/B2414JB
.366
9,30
.366
9,29
.202
5,13
BX2373JB/BX2369JB
B2414JB
Date Code
Country of Origin
.046
1,17
.098
2,49
.294
± .012
7,47
± 0,30
.362
± .008
9,20
± 0,20
SUGGESTED LAND PATTERN
.002/0,05
2 SURFACES
.291
± .006
7,40
± 0,15
Weight
. . . . . . . . . . . . . .4.0 grams
Tape & Reel
. . . . . . . . . . . .175/reel
Tray
. . . . . . . . . . . . . . . . . .105/tray
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .004
0,10
.472
12,00 MAX
.028 ± .004
0,71 ± 0,10
.098
2,49
.047
1,20
.294
± .012
7,47
± 0,30
.005/0,13
8 SURFACES
.055
1,40
.358 MAX
9,09
BX2373WA/BX2369WA/B2414WA
.366
9,30
.531
13,50
.374
9,50
.339
8,60
BX2373WA/BX2369WA
B2414WA
Date Code
Country of Origin
.492
12,50 MAX
.031
0,80
.079
2,00
.236
6,00
SUGGESTED LAND PATTERN
Weight
. . . . . . . . . . . . . .3.8 grams
Tape & Reel
. . . . . . . . . . . .190/reel
Tray
. . . . . . . . . . . . . . . . . .105/tray
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .004
0,10
.002/0,05
2 SURFACES
.461
11,70 MAX
8 X 0° 8
.008
0,20
.024
± .002
0,60
± 0,05
.079
2,00
.005/0,13
8 SURFACES
.036
± .006
0,91
± 0,15
.236
6,00
For More Information :
UNITED STATES
(Worldwide)
12220 World Trade Drive
San Diego, CA 92128
U.S.A.
http://www.pulseeng.com
TEL: 858 674 8100
FAX: 858 674 8262
UNITED KINGDOM
(Northern Europe)
1 & 2 Huxley Road
The Surrey Research Park
Guildford, Surrey GU2 5RE
United Kingdom
TEL: 44 1483 401700
FAX: 44 1483 401701
FRANCE
(Southern Europe)
Zone Industrielle
F-39270
Orgelet
France
TEL: 33 3 84 35 04 04
FAX: 33 3 84 25 46 41
SINGAPORE
(Southern Asia)
150 Kampong Ampat
#07-01/02
KA Centre
Singapore 368324
TEL: 65 287 8998
FAX: 65 280 0080
TAIWAN, R.O.C.
(Northern Asia)
3F-4, No. 81, Sec. 1
HsinTai Wu Road
Hsi-Chih, Taipei Hsien
Taiwan, R.O.C.
Tel: 886 2 2698 0228
FAX: 886 2 2698 0948
HONG KONG
(China/Hong Kong)
19/F, China United Plaza
1008 Tai Nan West Street
Cheung Sha Wan, Kowloon
Hong Kong, China
TEL: 852 2788 6588
FAX: 852 2776 1055
DISTRIBUTOR
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product
names mentioned herein may be trademarks or registered trademarks of their respective owners.
Printed on recycled paper. ©2002, Pulse Engineering, Inc.
B991.B (4/02)
