Wire-wound Chip Inductors - Open
ctparts.com
CT0603CS Series
From 1.6 nH to 390 nH
Part
Number
SPECIFICATIONS
Please specify tolerance code when ordering.
CT0603CS-1N6_
G = ±2%, J = ±5%, K = ±10%, M = ±20%
* J, K or M only
CT0603CSF
Please specify “F” for RoHS Compliant
Inductance
(nH)
1.6
1.8
3.6
3.9
4.3
4.7
5.1
5.6
6.3
6.8
7.5
8.2
8.7
9.5
10
11
12
15
16
18
22
23
24
27
30
33
36
39
43
47
56
68
72
82
100
110
120
150
180
220
270
330
390
L Test
Freq.
(MHz)
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
200
200
200
150
150
150
150
150
150
100
100
100
100
100
Q
Fact.
Min.
24
16
22
22
22
20
20
20
20
27
28
28
28
28
31
33
35
35
34
35
38
38
37
40
37
40
38
40
39
38
38
37
34
34
34
32
32
28
25
25
24
25
25
Q Test
Freq.
(MHz)
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
200
200
200
150
150
150
150
150
150
100
100
100
100
100
SRF
Min.
(MHz)
12500
12500
5900
6900
5900
5800
5700
5700
5700
5800
4800
4700
4600
5400
4800
4000
4000
4000
3300
3100
3000
2850
2650
2800
2250
2300
2080
2200
2000
2000
1900
1700
1700
1700
1400
1350
1300
990
990
900
900
900
900
DCR
Max.
Ω
(Ω)
.03
.05
.06
.08
.06
.12
.14
.14
.14
.11
.11
.11
.11
.14
.13
.09
.13
.17
.10
.17
.19
.19
.14
.22
.14
.22
.25
.25
.28
.28
.31
.34
.49
.54
.58
.61
.65
.92
1.3
1.9
2.8
3.9
4.4
Rated
DC
(mA)
700
700
700
700
700
700
700
700
700
700
700
700
700
700
700
700
700
700
700
700
700
700
700
600
600
600
600
600
600
600
600
600
400
400
400
300
300
280
240
200
170
100
100
ENGINEERING KIT #5
Not shown at actual size.
Compliant
Available
RoHS
CT0603CS_-1N6_*
CT0603CS_-1N8_*
CT0603CS_-3N6_
CT0603CS_-3N9_
CT0603CS_-4N3_
CT0603CS_-4N7_
CT0603CS_-5N1_
CT0603CS_-5N6_
CT0603CS_-6N3_
CT0603CS_-6N8_
CT0603CS_-7N5_
CT0603CS_-8N2_
CT0603CS_-8N7_
CT0603CS_-9N5_
CT0603CS_-10N_
CT0603CS_-11N_
CT0603CS_-12N_
CT0603CS_-15N_
CT0603CS_-16N_
CT0603CS_-18N_
CT0603CS_-22N_
CT0603CS_-23N_
CT0603CS_-24N_
CT0603CS_-27N_
CT0603CS_-30N_
CT0603CS_-33N_
CT0603CS_-36N_
CT0603CS_-39N_
CT0603CS_-43N_
CT0603CS_-47N_
CT0603CS_-56N_
CT0603CS_-68N_
CT0603CS_-72N_
CT0603CS_-82N_
CT0603CS_-R10_
CT0603CS_-R11_
CT0603CS_-R12_
CT0603CS_-R15_
CT0603CS_-R18_
CT0603CS_-R22_
CT0603CS_-R27_
CT0603CS_-R33_*
CT0603CS_-R39_*
CHARACTERISTICS
Description:
SMD ceramic core wire-wound high current
chip inductor
Applications:
Telecommunication equipment, mobile phones,
small size pagers, computers, printers and relevant equipment.
Also, audio & video applications and the automotive electronics
industry. High frequency applications
Operating Temperature:
-40°C to +125°C
Inductance Tolerance:
±2%, ±5%, ±10%, ±20%
Testing:
Inductance and Q are tested on an HP4287A at
specified frequency
Packaging:
Tape & Reel
Marking:
Reels are marked with inductance code and tolerance
Miscellaneous:
RoHS Compliant available.
Additional values
available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
1.8
0.07
B
Max.
1.12
0.044
C
Max.
1.02
0.04
D
0.76
0.03
E
0.33
0.013
F
0.86
0.034
G
0.38
0.015
PAD LAYOUT
01.14.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
