FLEXISAFE MLC Chips
General Specifications and Capacitance Range
For Ultra Safety Critical Applications
AVX have developed a range of components specifically for safety critical applications.
Utilizing the award-winning FLEXITERM™ layer in conjunction with the cascade design previously used for high
voltage MLCCs, a range of ceramic capacitors is now available for customers who require components designed
with an industry leading set of safety features.
The FLEXITERM™ layer protects the component from any damage to the ceramic resulting from mechanical stress
during PCB assembly or use with end customers. Board flexure type mechanical damage accounts for the majority
of MLCC failures. The addition of the cascade structure protects the component from low insulation resistance
failure resulting from other common causes for failure; thermal stress damage, repetitive strike ESD damage and
placement damage. With the inclusion of the cascade design structure to complement the FLEXITERM™ layer, the
FLEXISAFE range of capacitors has unbeatable safety features. Flexisafe capacitors are qualified in accordance
with AEC-Q200 standard. AEC-Q200 detailed qualification data is available on request
HOW TO ORDER
FS05
FS03 = 0603
FS05 = 0805
FS06 = 1206
FS10 = 1210
5
Voltage
16V = Y
25V = 3
50V = 5
100V = 1
C
Dielectric
X7R = C
104
Capacitance
Code (In pF)
K
Capacitance
Tolerance
J = ±5%
K = ±10%
M = ±20%
Q
Failure
Rate
Z
Z = FLEXITERM™
*X = FLEXITERM™
with 5% min lead
*Not RoHS Compliant
2
Packaging
2 = 7" Reel
4 = 13" Reel
A
Special
Code
Size
Terminations
2 Sig. Digits +
Number of
Zeros
e.g. 10μF =106
A = Commercial
4 = Automotive
Q = APS
A = Std.Product
CAPACITANCE RANGE FLEXISAFE X7R
SIZE
WVDC
102
182
222
332
472
682
103
123
153
183
223
273
333
473
563
683
823
104
124
154
224
334
474
1000
1800
2200
3300
4700
6800
0.01
0.012
0.015
0.018
0.022
0.027
0.033
0.047
0.056
0.068
0.082
0.1
0.12
0.15
0.22
0.33
0.47
16
G
G
G
G
G
G
G
G
G
G
G
FS03 = 0603
25
50
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
100
G
G
G
G
G
G
G
16
J
J
J
J
J
J
J
J
J
J
N
N
N
N
N
N
N
N
FS05 = 0805
25
50
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
100
J
J
J
J
J
J
J
J
J
J
N
N
N
N
N
N
N
N
16
J
J
J
J
J
J
J
J
J
J
J
J
J
M
M
M
M
M
M
M
FS06 = 1206
25
J
J
J
J
J
J
J
J
J
J
J
J
J
M
M
M
M
M
M
M
50
J
J
J
J
J
J
J
J
J
J
J
J
J
M
M
M
M
M
M
M
FS10 = 1210
16
25
50
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Letter
Max. Thickness
G
J
0.90 (0.035)
0.94 (0.037)
PAPER
M
1.27 (0.050)
N
1.40 (0.055)
EMBOSSED
Q
1.78 (0.070)
68
