55505 Flange Mount Hall Effect Geartooth Sensor
Features
•
Ferrous target sensing
•
Internal circuit protection
•
Protection against severe and
automotive environments
•
Self adjusting magnetic range
•
Automotive grade circuit protection
•
High speed operation
•
Short circuit and reverse voltage
protection
•
On board 10 bit A/D convertor
Benefits
•
No chopper delay
•
Rotational alignment to target not
critical
•
Immune to target run out
Applications
•
Wheel, transmission and camshaft
speed sensing
•
Gear tooth sensor
•
Rotary encoders
•
Industrial
•
Commercial
•
Automotive
DIMENSIONS (in) mm
(1.630)
41,40
(1.250)
31,75
BLOCK DIAGRAM
VDD
Pin 1
(Red)
(.866)
22,00
(.236)
6,00
(.197)
5,00
Table 1 +/-
(.393) 10,00
(.250)
6,35 Nom
R1
Rpu
Hall
Plate
C1
Switch
Comparator
Clock
Output
C2
(.260)
ø6,60
(.703)
ø17,86
(.937)
ø23,80
(.638)
ø16,20
GND
Pin 2
(Black)
OUT
Pin 3
(Blue)
SPECIFICATIONS
SPECIFICATIONS
Hall Type
Supply Voltage
Supply Voltage
Supply Voltage
Output High Voltage
Output Low Voltage
Output Current (continuously on)
Current Consumption
Current Consumption
Switching Speed
Temperature
Temperature
Operating
Storage
Operate
Overvoltage Protection
Reverse Voltage Protection
Vdc
Vdc-max.
Vdc-max.
Vdc
Vdc-max.
mA-max.
mA-max.
mA-max.
kHz-max.
o
C
o
C
Digital Switch 3 Wire (Voltage Output)
4.75 to 25.2
27
-25
VDD -2 (sinking output with internal pull-up)
0.6 @ 25mA
20
1
10.5
15
-40 to +125
-65 to + 125
APPLICATION EXAMPLE - Geartooth Sensor
CUSTOMER OPTIONS - Cable Length and Termination
TABLE 1
Cable Length:-
(CABLE 20 AWG, XLPE
Type TXL per SAE J-1128)
SELECT
OPTION
DESCRIPTION
TABLE 2
Termination Options:-
.197 (5mm)
Max.
SELECT
OPTION
LENGTH
mm
A
Tinned leads
01
02
(3,94) 100
(11,81) 300
(19,69) 500
(29,53) 750
(39,37) 1000
C
Molex MX 150
B
Deutsch DTM04-3P
Typical Output
03
04
05
ORDERING INFORMATION
55505
59036
Series 55505
Body Style
Cable Length
Termination
Hamlin USA
Hamlin UK
Hamlin Germany
Hamectrol France
Tel:
Tel:
Tel:
Tel:
XX
XX
T
X
Body Styles
00 - Standard body
01 - With O ring
Table 1
Table 2
INFORMATION PROVIDED ON THIS DATA SHEET IS PROVIDED FOR INFORMATION
PURPOSES ONLY AND SHOULD NOT BE RELIED UPON AS BEING ACCURATE FOR ANY
PARTICULAR PURPOSE. Product performance may be affected by the application to which the
product is applied. Upon request, HAMLIN will assist purchasers by providing information specific to
any particular application. HAMLIN disclaims any and all liability whatsoever for any purchaser’s
reliance upon the information contained on this data sheet without further consultation with
authorised representatives of HAMLIN.
+1 920 648 3000
•
Fax: +1 920 648 3001
•
Email: sales.us@hamlin.com
+44 (0)1379 649700
•
Fax: +44 (0)1379 649702
•
Email: sales.uk@hamlin.com
+49 (0) 6142 923920
•
Fax: +49 (0) 6142 923921
•
Email: sales.de@hamlin.com
+33 (0) 1 4687 0202
•
Fax: +33 (0) 1 4686 6786
•
Email: sales.fr@hamlin.com
Issue No.1 Date 01/05/06 DCR B4363
