ZM5304
Z-Wave
®
Serial
Interface Module
with Antenna
The ZM5304 serial interface
module with antenna takes
the RF design effort out
of Z-Wave. Designed for
easy integration and fast
time-to-market, it is ideal
in applications such as TVs, set-top boxes, and
gateways.
The ZM5304 is a fully self-contained module that includes a Z-Wave modem
and built-in antenna. The module comes with full FCC modular approval and is
pre-scanned for CE approval, making hardware intergration and approval very
simple. The ZM5304 provides hardware-assisted frequency agility, enabling
the module to switch away from a noisy channel without communication or
software overhead.
The ZM5304 module exposes the well-documented and proven Z-Wave
Serial API via USB or UART. As new Serial API features become available, the
ZM5304 firmware can be upgraded using the UART or USB ports, eliminating
the need to replace hardware. Existing products that use the Z-Wave Serial
API can be upgraded to the ZM5304 module without having to re-write their
interface software.
The ZM5304 continues to build on the Z-Wave ten-year track record of
backward-compatibility, enabling all generations of Z-Wave to communicate
seamlessly in a Z-Wave network.
POWERING THE NEW DIGITAL HOME:
SET-TOP BOXES
CONSUMER
ELECTRONICS
AV NETWORKS
HOME CONTROL
COMMERCIAL
SYSTEMS
KEY BENEFITS
• Easy integration
• Complete design from interface to
antenna
• An off-the-shelf solution
TARGET APPLICATIONS
• Gateways
• TVs
• Set-top boxes
KEY FEATURES
• Provides connection via Z-Wave serial
API interface
• UART, USB full-speed device connection
• Firmware upgrade using UART or USB
• Helical antenna on-board
• Hardware AES 128 security engine
• 2µA sleep mode
• 9.6/40/100 kbit/s data rates
• Regional modules for 868/908/921 MHz
• Hardware-assisted frequency agility with
up to 3 channels
• Battery monitor and built-in supply
regulators
• Power supply: 2.3-3.6V
• PCB module 27mm x 15.2mm x 5.5mm
ACTUAL SIZE
27mm x 15.2mm
ZM5304
Z-Wave
®
Serial Interface Module with Antenna
MODULE COMPARISON TABLE
ZM3102
Application
Type
Based on
Package
Frequency (MHz)
Bit-rate (kkbit/s)
FLASH Memory (kB)
SRAM (kB)
I/O
Key-Scan (# Keys)
IR Support
UART/SPI
USB 2.0 Device
Security 128-bit AES
Tx RF Power (dBm)
Rx Sensitivity (dBm)
Tx/Rx Current (mA)
Sleep Current (µA)
Battery to Battery (µA)
General Purpose
PCB Module
SD3301
PCB Module
13x14mm
868/908/921
9.6/40
32
2
10
None
None
1/1
None
Yes SW Only
-22 to -2
-102 @ 9.6kbit/s
36(@-2dBm) /23
2.5
80
ZM5202
General Purpose
PCB Module
w/ SAW Filter
SD3502
PCB Module
13x14mm
868/908/921
9.6/40/100
128
16
10
None
None
1/1
None
Yes HW
-26 to +2
-103 @ 9.6 kbit/s
41(@+2dBm) /32
1
50
ZM5101
Serial Interface
SiP w/o
SAW Filter
Die
QFN56
8x8mm
868/908/921
9.6/40/100
128
16
30
128
Transmit/Learn
2/2
1
Yes HW
-24 to +5
-104 @ 9.6kbit/s
32(@+3dBm) /32
1
50
ZM5304
Modem Only
PCB Module
w/ Ant. &
SAW Filter
SD3503
PCB Module
13x30mm
868/908/921
9.6/40/100
n/a
n/a
n/a
n/a
n/a
1/-
1
Yes HW
-26 to +2 (to antenna)
-103 @ 9.6kbit/s
41(@+2dBm) /32
2
n/a
ABOUT SIGMA DESIGNS
Sigma Designs is a leading provider of system-on-chip (SoC) solutions used to deliver entertainment and control
throughout the home:
Media Processing, Smart TV, Video Encoding, Home AV Networking, Video Processing, Home Control
These SoCs are supported with board-level reference designs, sophisticated system software, and technical
documentation to form a complete solution for a variety of set-top boxes, smart TVs, consumer electronics, AV network
devices, and home control systems.
FOR REGIONAL SALES OFFICES AND
DISTRIBUTOR CONTACT INFORMATION
Visit: www.sigmadesigns.com/sales
Email: sales@sigmadesigns.com
Headquarters
1778 McCarthy Blvd.
Milpitas, CA 95035
Main: +1.408.262.9003
Fax: +1.408.957.9740
www.sigmadesigns.com
Features subject to change without notice. Sigma Designs, HiDTV, Z-Wave, and the Sigma Designs logo are either registered trademarks or
trademarks of Sigma Designs, Inc. and its subsidiaries in the United States and other countries. All other trademarks or registered trademarks
are the property of their respective owners. These devices incorporate copy protection technology that is protected by U.S. patents and other
intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited. Devices that incorporate Rovi Corporation’s
Anti-Copy Process (ACP) technology may only be sold to Rovi Authorized Buyers. Copyright © 2013 Sigma Designs, Inc. All rights reserved.
Rev. 07.15.13 PMB12441
