CTA1

FEATURES:

•

Switching capacity up to 25A

•

Small size and light weight

•

PCB pin and quick connect mounting available

•

Suitable for automobile and lamp accessories

•

QS-9000, ISO-9002 Certified Manufacturing

22.8 x 15.3 x 25.8 mm

CONTACT DATA

Contact Arrangement

Contact Rating

Contact Resistance

Contact Material

Maximum Switching Power

Maximum Switching Voltage

Maximum Switching Current

1A = SPST N.O.

1C = SPDT

1A: 25A @ 14VDC

1C: 20A @ 14VDC

< 50 milliohms initial

AgSnO

350W

75VDC

25A

COIL DATA

Coil Voltage

VDC

Coil Resistance

Ω ±

10%

Pick Up Voltage

VDC (max)

75%

of rated voltage

Release Voltage

VDC (min)

10%

of rated voltage

Coil Power

Operate Time

Release Time

Rated

Max.

7.8

15.6

31.2

62.4

1.2W

120

480

1920

1.5W

384

1536

4.2

8.4

16.8

33.6

0.6

1.2

2.4

4.8

1.2 or 1.5

CAUTION:

1. The use of any coil voltage less than the rated coil voltage may compromise the operation of the relay.

2. Pickup and release voltages are for test purposes only and are not to be used as design criteria.

GENERAL DATA

Electrical Life @ rated load

Mechanical Life

Insulation Resistance

Dielectric Strength, Coil to Contact

Contact to Contact

Shock Resistance

Vibration Resistance

Terminal (Copper Alloy) Strength

Operating Temperature

Storage Temperature

Solderability

Weight

100K cycles, typical

10M cycles, typical

100MΩ min @ 500VDC

2500V rms min. @ sea level

1500V rms min. @ sea level

100m/s

for 11ms

1.27mm double amplitude 10-40Hz

8N (Quick Connect), 4N (PCB Pins)

-40

°C

to + 85

°C

-40

°C

to + 155

°C

230

°C ±

°C

for 10

0.5s

18.5g

Tel:

630-682-1542

Fax:

630-682-1562

Distributor: Electro-Stock www.electrostock.com
