ABH3B-26.000MHZ-C-1-Y-T datasheet, PDF

Datasheet> All Categories > Passive components> Crystal/resonator> ABH3B-26.000MHZ-C-1-Y-T

ABH3B-26.000MHZ-C-1-Y-T: DescriptionParallel - Fundamental Quartz Crystal, 26MHz Nom, SMD, 4 PIN; CategoryPassive components Crystal/resonator; File Size2MB，2 Pages; ManufacturerAbracon; Websitehttp://www.abracon.com/index.htm; Environmental Compliance

Download Datasheet Parametric View All

ABH3B-26.000MHZ-C-1-Y-T Overview

Parallel - Fundamental Quartz Crystal, 26MHz Nom, SMD, 4 PIN

ABH3B-26.000MHZ-C-1-Y-T Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1353704273
package instruction	SMD, 4 PIN
Reach Compliance Code	compliant
YTEOL	7.05
Other features	AEC-Q200; TR, 7 INCH
Ageing	5 PPM/FIRST YEAR
Crystal/Resonator Type	PARALLEL - FUNDAMENTAL
Drive level	10 µW
frequency stability	0.003%
frequency tolerance	10 ppm
load capacitance	10 pF
Installation features	SURFACE MOUNT
Nominal operating frequency	26 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-30 °C
physical size	L5.0XB3.2XH1.1 (mm)/L0.197XB0.126XH0.043 (inch)
Series resistance	50 Ω
surface mount	YES

Preview

Download Datasheet

View All

INDUSTRIAL GRADE GLASS SEALED

4 PADS SMD CRYSTAL

Pb in glass (exempt per

Preliminary. Contact

ABH3B

RoHS

Abracon for availability RoHS 2002/95/EC Annex (5))

Compliant

5.0 X 3.2 X 1.1mm

| | | | | | | | | | | | | | |

FEATURES:

• Automotive standard AEC-Q200 compliant.

• Ceramic package hermetically glass sealed assures high precision and reliability.

• IR-reflow capable

• Tight tolerance and stability available.

APPLICATIONS:

• Automotive applications

• Industrial applications

STANDARD SPECIFICATIONS:

PARAMETERS

ABRACON P/N

Frequency

Operation Mode

Operating Temperature

Storage Temperature

Frequency Tolerance

Frequency Stability over the

Operating Temperature

(Ref to + 25°C)

Equivalent Series Resistance

Shunt Capacitance C0

Load Capacitance CL

Drive Level

Aging (First Year) @ 25°C ± 3°C

Insulation Resistance

ABH3B Series

8.000 MHz to 40.000 MHz

AT cut fundamental

- 10°C to + 60°C (see options)

- 40°C to + 125°C

± 50 ppm max. (see options)

Table 1

Frequency (MHz)

8.000-9.999

10.000 - 15.999

16.000 - 40.000

ESR (

Ω

) max.

300

See table 1

5.0 pF max.

10 pF (see options)

100

W max., 10

W typical

± 5ppm max.

500 MΩ min at 100Vdc ± 15 Vdc

OPTIONS AND PART IDENTIFICATION: (Left blank if standard)

ABH3B -

Frequency in MHz

e.g. 4.000MHz

8.1592MHz

26.000MHz

Load Capacitance

Please specify CL in pF or

S for Series (8 to 33pF)

Please contact ABRACON for other

values

MHz

-R

Packaging

Blank: Bulk

T: Tape & Reel

ESR

Specify a value in Ω

Operating Temp.

E: 0°C ~ +70°C

B: -20°C ~ +70°C

C: -30°C ~ +70°C

N: -30°C ~ +85°C

D: -40°C ~ +85°C

J(***): -40°C to +105°C

K(***): -40°C to +125°C

Freq. Tolerance

1: ± 10 ppm

7: ± 15 ppm

2: ± 20 ppm

3: ± 25 ppm

4: ± 30 ppm

Freq. Stability

U: ± 10 ppm (*)

G: ± 15 ppm (**)

X: ± 20 ppm

W: ± 25 ppm

Y: ± 30 ppm

H: ± 35 ppm

Q: ± 100 ppm

R: ± 150 ppm

* -10 to +60Conly.

* * Option E, B, and -10 to +60Conly.

* * * Frequency stability ±100ppm, or ±150ppm only.

ontact ABRAC for tighter frequency stability.

ABRACON IS

ISO 9001 / QS 9000

ISO9001:2008

CERTIFIED

Revised: 02.15.10

30332 Esperanza, Rancho Santa Margarita, California 92688

tel 949-546-8000

fax 949-546-8001

| www.abracon.com

Visit www.abracon.com for Terms & Conditions of Sale
