20A & 30A Locking Devices
Hart-Lock
™
Complex Environment
Locking Devices
2.00"
(50.8mm)
2-Pole, 3-Wire Grounding
20A, 480V/AC
NEMA L8-20
Hart-Lock Plugs & Connectors
A
Rating
V/AC NEMA
Description
Cord
Diameter
Color
Plug
Catalog No.
Connector
Catalog No.
1.31"
(33.3mm)
20
480
L8-20
Watertight
Watertight
Severe Duty
0.36-0.84"
(9.1-21.3mm)
0.36-0.84"
(9.1-21.3mm)
0.38-1.00"
(9.5-25.4mm)
Y
BK
Y & BK
L820PW
L820PWBK
L820PY
L820CW
L820CWBK
L820CY
•
•
3.44"
(87.3mm)
2.12"
(53.8mm)
CRL530C
3.10" (78.7mm)
1.88"
(47.8mm)
Hart-Lock Receptacles
A
Rating
V/AC NEMA
Description
Color
Single Receptacle
Catalog No.
20
480
L8-20
Watertight
Watertight
Y
BK
L820RW
L820RWBK
4.60"
(116.8mm)
3.25"
(82.6mm)
Hart-Lock
™
Complex Environment
Locking Devices
Hart-Lock Plugs & Connectors
A
Rating
V/AC NEMA
Description
2-Pole, 3-Wire Grounding
30A, 125V/AC
NEMA L5-30
L530RW
Cord
Diameter
Plug
Catalog No.
Connector
Catalog No.
Color
30
125
L5-30
Watertight
Watertight
Severe Duty
SafetyGrip
Corrosion Resistant
0.43-1.15"
Y
(10.9-29.2mm)
0.43-1.15"
BK
(10.9-29.2mm)
0.38-1.00"
(9.5-25.4mm)
0.38-1.00"
(9.5-25.4mm)
Y & BK
Y
L530PW
L530PWBK
L530PY
CRL530P
L530CW
L530CWBK
L530CY
CRL530C
•
•
•
Hart-Lock Receptacles
A
Rating
V/AC NEMA
Description
Color
Single Receptacle
Catalog No.
30
125
L5-30
Watertight
Watertight
Corrosion Resistant
Y
BK
Y
L530RW*
L530RWBK*
CRL530R
•
•
•
* Not Fed. Spec.
Dimensional Information:
D-33
Specification Information:
Watertight Industrial Plugs &
Connectors: D-36
Watertight Industrial
Receptacles: D-37
Severe Duty Industrial
Plugs & Connectors: D-38
Corrosion Resistant: D-39
Color Information:
BK
(Black)
Colors: BK (Black), Y (Yellow)
Y
(Yellow)
Specifications and availability are subject to change without notice.
Indicates NAFTA Compliant - Page R-30
