PHOTONIC
Silicon Photodiode, Blue Enhanced Photovoltaic
Type PDB-V109
DETECTORS INC.
PACKAGE DIMENSIONS INCH [mm]
Ø0.483 [12.27]
Ø0.449 [11.39]
WIRE
BONDS
0.215 [5.46]
0.065 [1.65]
1.50 [38.1]
C
L
Ø0.550
[13.97]
79°
VIEWING
ANGLE
0.295 [7.49]
ANODE
Ø0.018 [0.46]
C
L
CATHODE
Ø0.018 [0.46]
HEADER
WINDOW CAP
(WELDED)
PHOTODIODE
0.340 [8.64]
0.230 [5.84]
0.209 [5.31] ACTIVE AREA
TO-8 HERMETIC PACKAGE
0.319 [8.10] ACTIVE AREA
ACTIVE AREA = 42.86 mm
2
FEATURES
Low noise
Blue enhanced
High shunt resistance
High response
DESCRIPTION
The
PDB-V109
is a silicon, PIN planar
diffused, blue enhanced photodiode. Ideal
for low noise photovoltaic applications.
Packaged in a hermetic TO-8 metal can
with a flat window.
RESPONSIVITY (A/W)
0.7
0.6
0.5
0.4
0.3
0.2
0.1
APPLICATIONS
Instrumentation
Industrial controls
Photoelectric switches
Encoder sensors
SPECTRAL RESPONSE
0
=1
0%
ABSOLUTE MAXIMUM RATING
(TA=25
O
C unless otherwise noted)
SYMBOL
PARAMETER
MIN
MAX
UNITS
V
BR
T
STG
T
O
T
S
I
L
Reverse Voltage
Storage Temperature
Operating Temperature Range
Soldering Temperature*
Light Current
-55
-40
75
+150
+125
+240
0.5
V
O
O
O
C
C
C
QE
1000
mA
*1/16 inch from case for 3 secs max
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS
(TA=25
O
C unless otherwise noted)
SYMBOL CHARACTERISTIC TEST CONDITIONS
MIN
TYP
I
SC
I
D
R
SH
TC R
SH
C
J
Short Circuit Current
Dark Current
Shunt Resistance
R
SH
Temp. Coefficient
Junction Capacitance
Spectral Application Range
Spectral Response - Peak
Breakdown Voltage
Noise Equivalent Power
Response Time
H = 100 fc, 2850 K
H = 0, V
R
= 10 mV
H = 0, V
R
= 10 mV
H = 0, V
R
= 10 mV
H = 0, V
R
= 0 V**
Spot Scan
Spot Scan
I = 10
mA
V
R
= 10 mV @ Peak
RL = 1 KΩ V
R
= 0 V
20
350
950
30
1.0x10
-14
1,000
50
405
500
66
150
-8
4,500
MAX
200
UNITS
m
A
pA
M
Ω
% /
o
C
pF
λ
range
λ
p
V
BR
N EP
tr
1100
nm
nm
V
W/
nS
Hz
Information in this technical data sheet is believed to be correct and reliable. However, no responsibility is assumed for possible inaccuracies or omission. Specifications
are subject to change without notice.**f = 1 MHz
[FORM NO. 100-PDB-V109 REV B]
