PHOTONIC
Silicon Photodiode, Blue Enhanced Photoconductive
Quadrant Type PDB-C206
DETECTORS INC.
PACKAGE DIMENSIONS INCH [mm]
0.625 [15.88] SQ
4X Ø0.078
HOLE
C
L
0.425 [10.79]
0.100 [2.54]
0.100 [2.54]
C
L
C
L
C
L
WIRE
BONDS
0.075 [1.91]
P.W.B.
0.212 [5.40]
0.100 [25.4]
MAX
0.062 [1.57]
0.425 [10.79]
PDI
C
L
0.050 [1.27] TYP
C
L
CATHODE
4X ANODE
ACRYLIC
CONFORMAL
COATING
0.1325 [3.366] SQ
ACTIVE AREA
4 PLACES
5X Ø0.028 HOLES
CHIP
C
L
WIRE BOND
POTTING
0.010 [0.25]
GAP TYP
P.C.B. CHIP ON BOARD PACKAGE
ACTIVE AREA = 11.33 mm
2
PER ELEMENT
FEATURES
Narrow gap
P.C.B. mount
Blue enhanced
Large active area
DESCRIPTION
The
PDB-C206
is a silicon, pin planar
diffused, blue enhanced large area quadrant
photodiode. Each element is 11.33 mm
2
with a .010 inch (0.25 mm) gap. Packaged
on a .062 inch thick P.C.B. chip on board.
RESPONSIVITY (A/W)
0.7
0.6
0.5
0.4
0.3
0.2
0.1
APPLICATIONS
Optical alignment
Position sensing
Edge sensing
Instrumentation
SPECTRAL RESPONSE
0
=1
0%
ABSOLUTE MAXIMUM RATING
(TA=25
O
C unless otherwise noted)
SYMBOL
PARAMETER
MIN
MAX
UNITS
V
BR
T
STG
T
O
T
S
I
L
Reverse Voltage
Storage Temperature
Operating Temperature Range
Soldering Temperature*
Light Current
-50
-40
100
+125
+100
+240
0.5
V
O
O
O
C
C
C
QE
1000
mA
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS
(TA=25
O
C unless otherwise noted)
SYMBOL CHARACTERISTIC TEST CONDITIONS
MIN
TYP
I
SC
I
D
R
SH
TC R
SH
C
J
Short Circuit Current
Dark Current
Shunt Resistance
R
SH
Temp. Coefficient
Junction Capacitance
Spectral Application Range
Spectral Response - Peak
Breakdown Voltage
Noise Equivalent Power
Response Time
H = 100 fc, 2850 K
H = 0, V
R
= 10 V
H = 0, V
R
= 10 mV
H = 0, V
R
= 10 mV
H = 0, V
R
= 10 V
Spot Scan
Spot Scan
I = 10
mA
V
R
= 10 V @ Peak
RL = 1 KΩ V
R
= 10 V
50
350
950
75
1.0x10
-14
25
50
100
185
10
100
-8
50
MAX
50
UNITS
m
A
nA
M
Ω
% /
o
C
pF
λ
range
λ
p
V
BR
N EP
tr
1100
nm
nm
V
W/
nS
Hz
Information in this technical data sheet is believed to be correct and reliable. However, no responsibility is assumed for possible inaccuracies or omission. Specifications
are subject to change without notice.
[FORM NO. 100-PDB-C206 REV A]
