Power Inductors
ctparts.com
SPECIFICATIONS
CTCMD4D06 Series
From 2.2 µH to 47 µH
Part
Number
CTCMD4D06_-2R2M
CTCMD4D06_-3R3M
CTCMD4D06_-4R7M
CTCMD4D06_-6R8M
CTCMD4D06_-100M
CTCMD4D06_-150M
CTCMD4D06_-220M
CTCMD4D06_-330M
CTCMD4D06_-470M
Not shown at actual size.
Parts are available in ±20% inductance tolerance only.
CTCMD4D06F
Please specify “F” for RoHS Compliant
*Rated Current: Inductance drop = 10% typ.
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω )
0.116
0.174
0.216
0.296
0.457
0.676
1.066
1.647
2.843
Rated Current*
Max.
(A)
0.95
0.77
0.75
0.62
0.5
0.4
0.3
0.24
0.18
Inductance
(µH ±20%)
2.2
3.3
4.7
6.8
10
15
22
33
47
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
6.3
0.248
B
Max.
5.8
0.228
C
Max.
0.8
0.031
D
3.5
0.138
E
4.1
0.161
F
3.2
0.126
G
0.5
0.020
H
0.4
0.016
CHARACTERISTICS
Description:
SMD power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-25°C to +85°C
Inductance Tolerance:
±20%
Testing:
Tested on a HP4285A at 100 KHz , 1V
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
4
A
D
1
C
H
1
E
1
4
G
XXX
3
2
B
2
F
2
3
Marking: Inductance Code
4
1
PAD LAYOUT
3
Unit: mm
2
Bottom View
3.2
0.9
4.0
7.0
03.14.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
