EZI
Main Feature
1. Low power consumption; AC/DC coil available.
2. Proper insulation distance with 5000VAC dielectric
strength.
3. Contacts pin out width 5.0 mm.
4. UL Class F insulation available.
5. In accordance with IEC 60335-1 and IEC 60730-1.
6. Halogen Free available.
7. Comply with RoHS and REACH regulations
Contact Rating
EZI (DM/DB)
12A 250VAC
Rated Load (Resistive)
12A 30VDC
Rated Carrying Current
12A
AC 250V
Max. Allowable Voltage
DC 300V
Max. Allowable Current
12A
Max. Allowable Power
3,000VA
Force
360W
Contact Material
Ag Alloy
Contact Form
SPST
Max Allowable Voltage: 300VDC@0.3A
Load Type
EZI (D)
12A 250VAC
12A 30 VDC
12A
AC 250V
DC 300V
12A
3,000VA
360W
Ag Alloy
SPDT
EZI (AM/AB)
12A 250VAC
12A 30VDC
12A
AC 250V
DC 300V
12A
3,000VA
360W
Ag Alloy
SPST
EZI (A)
12A 250VAC
12A 30VDC
12A
AC 250V
DC 300V
12A
3,000VA
360W
Ag Alloy
SPDT
Application
Cooking Appliance, Audio Equipment, Domestic
Appliance and Controlling Equipment, etc.
Performance (at Initial Value)
Contact Resistance ............. 100 mΩ Max.
@
1A,6VDC
Operate Time ...................... 12 mSec. Max.
Release Time ...................... 8 mSec. Max.
Dielectric Strength:
Between Coil & Contact....... 5,000VAC at 50/60 Hz
for one minute
Between Contacts ............... 1,000VAC at 50/60 Hz
for one minute
Surge Strength .................... 10,000V (between coil
& contact 1.2x50µSec.)
Insulation Resistance .......... 100MΩ Min. at
500VDC
Max. On/Off Switching:
Electrical
...............................
6 Cycles per Minute
Mechanical .......................... 300 Cycles per Minute
Temperature Range ............ -40~+85
°C
Humidity Range ................... 45~85% RH.
Coil Temperature Rise ........ 30
°C
Max.
Vibration:
Endurance............................10 to 55 Hz dual
amplitude width 1.5 mm
Error Operation ....................10 to 55 Hz dual
amplitude width 1.5 mm
Shock:
2
Endurance ..........................1,000 m/S
2
Error Operation ....................100 m/S
Life Expectancy:
5
Electrical...............................10 Operations at
Rated Resistive Load
7
Mechanical ...........................10 Operations at
No load condition
Weight..................................About 15 g
Accessories & Sockets
PI-50BE................................See Page 179
PI-50BE/3.............................See Page 179
PI-50-0 .................................See Page 181
Safety Standard & File Number
UL & C-UL............................E141060
VDE......................................40009648
CQC……………………….….02001002513
EZI
Coil Specification (at 20
°
C)
Coil Sensitivity
Nominal
Voltage
(VAC/VDC)
6
9
12
15
18
24
48
60
110
24
115
230
Nominal Current
(mA)
50HZ
60HZ
Coil
Resistance
(±10%)
50HZ
60HZ
Power
Consumption
(DC: W; AC: VA)
50HZ
60HZ
Pull-In
Voltage
Drop-Out Voltage
Maximum
Allowable
Voltage
EZI
DC Coil
EZI
AC Coil
66.7
44.6
33.3
26.6
22.3
16.7
8.7
8.2
4.1
29.75
25.35
7.65
6.3
3.42
2.72
90
202
360
560
810
1,440
5,520
7,340
26,530
350
8,100
32,500
Abt. 0.40
80%
Maximum
5%
Minimum
130%
0.71
0.88
0.79
0.61
0.73
0.63
30%
Minimum
Ordering Information
EZI -
SS
-
1
12
D
M - G
F
Insulation System:
Contact Material:
Nil:
Standard Class
F:
Class F
Nil:
AgNi
G:
AgNi Gilded
O:
AgNi Plated
N:
AgSnO
2
S:
AgSnO
2
Gilded
C:
AgCdO
Nil:
One Form C
M:
One Form A
B:
One Form B
D:
Standard DC
A:
Standard AC
VDC (06: 6V,
09:
9V,
12:
12V,
15:
15V,
18:
18V,
24:
24V,
48:
48V,60: 60V,
110:
110V)
VAC (24: 24V,
115:
115V,
230:
230V)
1:
One Pole
SS:
RT
II
Flux Proofed
SH:
RT
III
Wash Tight
EZI
Contact Form:
Coil Type:
Coil Voltage:
Number of Pole:
Type of Sealing:
Type:
Classification
Model
Coil Sensitivity
Contact Form
Flux Proofed
Wash Tight
EZI
DC Coil
1C
1A
1B
EZI-SS-1□□□D EZI -SS-1□□□DM EZI -SS-1□□□DB
EZI-SH-1□□□D EZI -SH-1□□□DM EZI -SH-1□□□DB
1C
EZI -SS-1□□□A
EZI -SH-1□□□A
AC Coil
1A
1B
EZI -SS-1□□□AM EZI -SS-1□□□AB
EZI -SH-1□□□AM EZI -SH-1□□□AB
Dimension (
≤
5mm+ 0.2mm, > 5mm + 0.3mm, the tolerance of PCB thru hole: +0.1mm)
20
P.C.B. Layout
Bottom View
