Size, speed, range, power consumption and cost are all important

issues to engineers integrating RF connectivity. AeroComm

addresses these issues with compact 2.4GHz, 900MHz & 868MHz

transceivers. Designed for fast OEM integration, our radios suit

applications where

both

high reliability

and

long range are essential.

AeroComm’s Design Kits provide a complete development envi-

ronment to help engineers get up and running with our solutions in

a matter of minutes. Each system includes the transceivers and

accessories required to install and test RF, allowing for reduced

R&D costs, quick agency certification and fast time to market.

Design Kits are not just for engineers working with tight resources, limited time or

varying experience—all OEMs can benefit from our comprehensive tools and highly

technical expertise in the complex field of RF.

Software

Testing and tuning antennas

Increasing transmission range

Optimizing system timing

Mechanical engineering

Hardware and software integration

Finding best mode for data rate & network

Finding best configuration for application

Help with agency certification

In an easy menu-driven format, our Windows-

compatible software provides several helpful

development utilities, allowing OEMs to quickly

begin performing tests for configuration modes,

range measurements, antenna evaluations,

power management and data throughput. Plus,

designers can easily program the transceivers to

any desired configuration with the EEPROM

Viewer/Editor feature.

Configuration

Two (2) Transceivers

Choose from AeroComm’s 2.4GHz, 900MHz or 868MHz kits. Market-

ready modules help you to determine actual transmission range for

your application, evaluate data throughput in the field, and choose

best mechanical fit.

RS232, RS485, 5V/3.3V serial TTL and USB interfaces supported.

More features include: 1) loop-back feature for distance-testing using

one computer, 2) status/communications LED indicators, 3) switches

for easy configuration & reset, 4) test points for troubleshooting.

Script-driven utilities include: 1) transmit/receive emulator, 2) single-

line command interface, 3) EEPROM viewer/editor; configuration infor-

mation storage file, 4) “What’s This?” Help File format provides

description of each configuration option, 5) error-checking prevents

configuration errors.

Power for adapter board & transceiver. USB & battery power optional.

Connect the adapter board to PC via DB9.

All AeroComm transceivers have configuration

parameters stored in EEPROM that are used to

customize the Serial Interface Mode and provide

for general system setup. The modules ship with

default parameters already configured to enable

plug-and-play; these can be changed using our

development tools or with custom interfaces

developed by the OEM.

Two (2) Adapter Boards

Antennas

Antenna type, gain and location are among

the most critical elements of a wireless system.

AeroComm’s Design Kit allows OEMs to connect

different antennas and evaluate their perform-

ance in various situations. In addition, our engi-

neers can provide a comprehensive antenna

review during the design process to determine

the best antenna and location for the application.

One (1) Utilities CD

Two (2) AC Power Adapters

Two (2) DB9 Serial Cables

Two (2) USB Cables

Two (2) Dipole Antennas

Compliance

Connect the adapter board to PC via USB.

Convenient, small, cost-efficient dipole antennas plug directly into

transceiver’s MMCX connector; longer-range antennas available.

AeroComm’s team is available to assist with development, integration,

and agency certification processes.

RF products are required to meet regulatory

compliance such as FCC (USA), IC (Canada),

ETSI (Europe). Our transceiver approvals will

help eliminate significant costs and time, yet reg-

ulatory compliance is still required for the final

product. AeroComm’s experts can help guide

OEMs through the approval process.

Engineering Expertise
