VOLTAGE CONTROLLED CRYSTAL OSCILLATORS
(SMD • Ceramic Package)
RoHS compliant
CSX-750V SERIES
■
FEATURES
2000pcs/reel
7Available
to supply voltage 5.0V or 3.3V.
7Most
appropriate for communication devices and
other equipment.
7Output
enable function (OE) can be used for low
power consumption.
Life-size
■
DIMENSION [mm]
Pin Assignment
Pin No.
Connection
VC
#1
#2
NC
GND
#3
OUT
#4
OE
#5
#6
Vdd
Function
#5 input #4 Output condition
H
Oscillation out
Open
Oscillation out
Oscillation stop
L
■
SOLDER PAD LAYOUT [mm]
2.54
2.54
7.0±0.15
1.4
#1
5.08
#2
5.0±0.15
#3
1.1
1.6 Max.
4.2
2.6
1.8
#6
#5
#4
■
STANDARD SPECIFICATIONS
Item
Frequency Range
Supply Voltage
Frequency Stability
Operating Temperature Range
Storage Temperature Range
Pulling range
Frequency control voltage
Current consumption
Disable current
Linearity
Duty
Output Voltage
Output Load
Rise and Fall Time
Start-up time
Modulation band width
Phase Noise
CMOS level(1/2 Vdd)
(*)
Model
* Model is determined by the supply voltage and the frequency stability.
CSX-750 VJ
*)
(
M
Vdd : 5.0V±0.5V
CSX-750 VK
(*)
L
Vdd : 3.3V±0.3V
2.000MHz ∼ 40.000MHz
B : ±50ppm
−
20℃∼
+
70℃) E : ±50ppm
−
40℃∼
+
85℃)
(
,
(
−
20℃∼
+
70℃
−
40℃∼
+
85℃)
(
−
55℃∼
+
125℃
M : ±100ppm Min. / Vc=2.5±2.0V
2.5±2.0V
(at 25℃)
15mA Max.
10mA Max.
L : ±90ppm Min. / Vc=1.65±1.65V
1.65±1.65V
(at 25℃)
10mA Max.
6mA Max.
10% Max.
45∼55%
V
OH
V
OL
Vdd
−
0.4V Min.
0.4V Max.
CMOS 30pF Max.
6 nsec Max.
0.9Vdd Min.
0.1Vdd Max.
(tr,tf)
4 msec Max.
15kHz Min.
(Gain
−
3dB)
−
120dBc/Hz Max.
(Offset 1kHz)
http://cfm.citizen.co.jp/english/product/pr02.html
