REVISIONS
REV.
ECO. NO
1839
1845
1909
2537
2915
DESCRIPTION
INITIAL RELEASE
UPDATE NOTE 12 & TOLERANCE BLOCK,
ADD TOLERANCE TO DIM. .398[10.10]
UPDATE NOTES
UPDATE NOTE 10 PROCESSING TEMPERATURE
ADD 'N' MATERIAL OPTION & UPDATE NOTES
DATE
11/3/2008
11/6/2008
2/4/2009
02/29/2012
2/6/2014
BY
JH
JH
JH
LH
NC
F
B
F
A
B
.100 2.54
.024 0.60
.100 2.54
.016 0.40
.106 2.70
C
D
E
PRELIMINARY
.335 8.50
.398±.010 10.10±0.25
E
A
.276 7.00
E
.100 2.54
A A
D
.146 3.70
.039 1.00
D
.242 6.16
.102 2.60
SECTION A-A
SCALE 3 : 1
A
C
.040 1.02
.100 2.54
C
.100 2.54
B
RECOMMENDED PCB HOLE LAYOUT
B
A
NOTES:
1. INSULATOR MATERIAL: SEE PART NUMBER CODING.
2. CONTACT MATERIAL: SEE PART NUMBER CODING.
3. PLATING: SEE PART NUMBER CODING.
4. CONTACT RESISTANCE: 20m OHMS MAX.
5. OPERATING TEMPERATURE: -40 C TO +105 C.
6. UL FLAMMABILITY RATING: 94V-0.
7. CURRENT RATING: 3.0 AMPS PER CONTACT.
8. INSULATOR RESISTANCE: 1,000M OHMS MIN.
9. DIELECTRIC WITHSTANDING: 500 VAC
10. PROCESSING TEMP.: SEE PART NUMBER CODING.
11. MATES WITH SBH11 SERIES.
12. FOR PCB CONNECTOR.
8
7
6
PIN 1
DRAWN
DATE
11/3/2008
NAME
JH
TITLE
Pb
PIN 2
RoHS
COMPLIANT
5
4
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
TOLERANCES:
ANGULAR:
DECIMALS
.XX= .012 [.3]
.XXX= .008 [.20]
.XXXX= .0040 [.100]
3
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
PART NUMBER
SIZE
HEADER FEMALE, .100[2.54] CC, RA
CAGE CODE
A
SFH11- _ _ _ C-D _ _ -RA- _ _
DWG. NO.
SCALE: 2:1
2
C
54453
11161
REV
SHEET 1 OF 1
1
E
FILE NAME: 11161 SFH11- _ _ _ C-D _ _ -RA- _ _
