DPPS10S18K datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> DPPS10S18K

DPPS10S18K: DescriptionFilm Capacitor, Polypropylene, 1000V, 10% +Tol, 10% -Tol, 0.018uF, Through Hole Mount, RADIAL LEADED; CategoryPassive components capacitor; File Size76KB，9 Pages; ManufacturerCDE [ CORNELL DUBILIER ELECTRONICS ]

Download Datasheet Parametric View All

DPPS10S18K Overview

Film Capacitor, Polypropylene, 1000V, 10% +Tol, 10% -Tol, 0.018uF, Through Hole Mount, RADIAL LEADED

DPPS10S18K Parametric

Parameter Name	Attribute value
Objectid	2013321083
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
YTEOL	0
capacitance	0.018 µF
Capacitor type	FILM CAPACITOR
dielectric materials	POLYPROPYLENE
JESD-609 code	e3
Installation features	THROUGH HOLE MOUNT
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
positive tolerance	10%
Rated (AC) voltage (URac)	450 V
Rated (DC) voltage (URdc)	1000 V
surface mount	NO
Terminal surface	TIN
Terminal shape	WIRE

Preview

Download Datasheet

View All

Pulse and High-Frequency, Radial-Leaded Polypropylene Capacitors

Types DPP, DPPS, DPFF,

DPPM, DPMF

Highlights

Type DPP is standard film/foil construction. Types

DPPS and DPFF are series-wound extended foil

with a floating common foil for 800 Vdc and up.

Types DPPM and DPMF are similar except use

metallized polypropylene film for the floating

common foil for 800 Vdc and up. This alternate

construction cuts the capacitor volume by almost

half.

Specifications

Voltage Range:

250-2000 Vdc (140-500

Vac)

Capacitance Range:

.001-1

µF

Operating Temperature Range:

-55°C to

85°C

.12

3.0 max.

.79

20 min.

Choose with confidence any of these high peak

current, radial-leaded, polypropylene, film/foil

capacitors for your snubber application. They

are offered here for easy use in snubbers with

the highest peak current ratings listed first.

Pulse, Hi-Frequency

& Snubber

Capacitors

Ratings

Cap.

µF

.010

.012

.015

.018

.022

.027

.033

.039

.047

.056

.068

.082

Catalog

Number

DPP2S1K

DPFF2S12J

DPP2S15K

DPFF2S15J

DPFF2S18J

DPP2S22J

DPFF2S22J

DPFF2S27J

DPFF2S33J

DPP2S33K

DPMF2S39K

DPFF2S39J

DPMF2S47K

DPP2S47K

DPFF2S56J

DPP2S68K

DPFF2S68J

DPMF2S82K

in. (mm)

.590

.700

.591

.750

.700

.591

.750

.700

.750

.788

.700

.900

.700

.788

.900

.788

.950

(15.0)

(17.8)

(15.0)

(19.1)

(17.8)

(15.0)

(19.1)

(17.8)

(19.1)

(20.0)

(17.8)

(22.9)

(17.8)

(20.0)

(22.9)

(20.0)

(24.1)

in. (mm)

.470

.320

.473

.370

.350

.512

.420

.390

.420

.551

.560

.380

.580

.630

.430

.630

.450

.600

(12.0)

(8.1)

(12.0)

(9.4)

(8.9)

(13.0)

(10.7)

(9.9)

(10.7)

(14.0)

(14.2)

(9.7)

(14.7)

(16.0)

(10.9)

(16.0)

(11.4)

(15.2)

in. (mm)

.280

.260

.300

.370

.290

.315

.420

.330

.420

.335

.320

.340

.354

.370

.433

.450

.360

(7.0)

(6.6)

(7.5)

(9.4)

(7.4)

(8.0)

(10.7)

(8.4)

(10.7)

(8.5)

(8.1)

(8.6)

(9.0)

(9.4)

(11.0)

(11.4)

(9.1)

in. (mm)

.394

.374

.390

.374

.390

.374

.370

.590

.375

.374

.375

.590

.374

.590

.370

.375

(10.0)

(9.5)

(10.0)

(9.5)

(10.0)

(9.5)

(9.4)

(15.0)

(9.5)

(15.0)

(9.5)

(15.0)

(9.4)

(9.5)

in. (mm)

.024

.032

.024

.032

.024

.032

.024

.032

.024

.032

.024

.032

(.6)

(.8)

(.6)

(.8)

(.6)

(.8)

(.6)

(.8)

(.6)

(.8)

(.6)

(.8)

Ipk

Amps

100

150

100

120

150

140

170

210

190

130

280

160

190

Irms, Amps

1 kHz 10 kHz 100 kHz

.009

.012

.013

.015

.018

.019

.021

.026

.032

.029

.038

.046

.041

.055

.060

.066

.080

.088

.12

.13

.15

.18

.19

.21

.26

.32

.29

.38

.46

.41

.55

.60

.66

.80

.55

.66

.69

.74

.81

.86

.90

1.10

1.20

1.30

1.40

1.60

1.80

2.00

2.20

250 Vdc (155 Vac)
