Crystal unit
Product Number (please contact us
)
Q22FA1280xxxx00
MHz RANGE CRYSTAL UNIT
FA - 128
Nominal
frequency range
External
dimensions
Overtone
order
Applications
:
:
:
:
:
16 MHz to 54 MHz
2.0 × 1.6 × 0.5 mm
Fundamental
Mobile phone, Bluetooth, W-LAN
ISM band radio, Clock for MPU
Actual size
Specifications (characteristics)
Item
Nominal frequency range
Storage temperature range
Operating temperature range
Level of drive
Frequency tolerance
(standard)
Frequency versus
temperature characteristics
(standard)
Load capacitance
Motional resistance (ESR)
Frequency aging
Symbol
f_nom
T_stg
T_use
DL
f_tol
f_tem
C
L
R
1
f_age
Specifications
For RF Reference
For Clock
16.000 MHz to 54.000 MHz
-40
C
to +125
C
-40
C
to +85
C
100
W
Max.
200
W
Max.
10
10
-6
10
10
-6
*1
Conditions / Remarks
Fundamental
Please contact us about available frequencies.
Storage as single product.
Recommended: 1 to 100
W
+25
C,
Please contact us for requirements
not listed in this specifications.
-20
C
to +75
C,
Please contact us for
requirements not listed in this specifications.
30
10
-6
30
10
-6
*1
6 pF to
Please specify.
As per table below
-20
C
to +75
C
-6
-6
1
10 / year Max.
5
10 / year Max. +25
C,
First year
*1
Please contact us for available frequency tolerances as they are dependent upon the nominal frequency.
Motional resistance (ESR)
Frequency
16.0 MHz
f_nom < 18.0 MHz
18.0 MHz
f_nom < 20.0 MHz
20.0 MHz
f_nom < 24.0 MHz
24.0 MHz
f_nom < 26.0 MHz
26.0 MHz
f_nom
54.0 MHz
Product name
(Standard form)
Motional resistance
200
Max.
150
Max.
100
Max.
80
Max.
60
Max.
FA-128 24.000000MHz 12.0 +10.0-10.0
①
②
③
④
-6
①Model
②Frequency
③Load
capacitance(pF)
④Frequency
tolerance(
×
10
,
+25
C)
In addition to the above mentioned specification item, please specify frequency temperature characteristics
and operating temperature range in case of inquiry.
(Unit:mm)
External dimensions
2.0±0.1
#4
#3
Footprint (Recommended)
(Unit:mm)
1.6±0.1
2600M
E 66R A
#1
#2
1.45
0.5 Max.
0.65
#1
0.6
#2
0.45 0.5
#4
#1
Internal c onnection
(TO P VIEW )
#3
#2
1.15
0.85
C 0.2 Min.
0.95
#4
#3
#2 and #4 are connected to the co ve r.
(Please connect to ground)
