TSR6GTF2263V datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> TSR6GTF2263V

TSR6GTF2263V: DescriptionFixed Resistor, Metal Glaze/thick Film, 0.125W, 226000ohm, 150V, 1% +/-Tol, -100,100ppm/Cel, 0805,; CategoryPassive components The resistor; File Size849KB，2 Pages; ManufacturerTateyama Kagaku Group

Download Datasheet Parametric View All

TSR6GTF2263V Overview

Fixed Resistor, Metal Glaze/thick Film, 0.125W, 226000ohm, 150V, 1% +/-Tol, -100,100ppm/Cel, 0805,

TSR6GTF2263V Parametric

Parameter Name	Attribute value
Objectid	297352465
Reach Compliance Code	unknown
ECCN code	EAR99
structure	Chip
Number of terminals	2
Maximum operating temperature	155 °C
Minimum operating temperature	-55 °C
Package height	0.5 mm
Package length	2 mm
Package form	SMT
Package width	1.25 mm
method of packing	Tape
Rated power dissipation(P)	0.125 W
resistance	226000 Ω
Resistor type	FIXED RESISTOR
size code	0805
technology	METAL GLAZE/THICK FILM
Temperature Coefficient	100 ppm/°C
Tolerance	1%
Operating Voltage	150 V

Preview

Download Datasheet

View All

TSR_G

角½厚膜チップ抵抗器/

Thick Film Chip Resistors

Wireless

Module

Sensor

Device

■ 外½寸法

½状

Type

TSR20G

TSR16G

TSR3G

TSR6G

TSR8G

TSR4G

TSR2G

TSR5G

TSR1G

■ ½品構造/特長

保護膜

Protective Coating

Construction/ Feature

外装メッキ

Outer plating

下地メッキ

Inner plating

抵抗

Resistive Element

高純度アルミナ基板

High Purity Alumina Substrate

内部電極

Inner Electrode

・0603から6332の9½状でシリーズを構成しています。

・TSR_G

series consist of 9 types from 0201 to 2512 inch.

・３層構造の電極とメタルグレーズ厚膜抵抗½により、高い信頼性が得られます。

・High

reliability with triple layers of electrodes and metal graze thick film resistive

element.

・リフロー、フローはんだ付けのいずれにも対応します。

・Suitable

for both flow and reflow soldering.

・

AEC－Q200にも対応可½です。

・

Supports for AEC-Q200 is available.

■ 品番構成

Type Designation

TSR

品種

Product Code

½状、特性

Size, Characteristics

表示

Marking

T=表示有り

T=Marking

空½=表示無し

Nil=No Ma rking

抵抗値許容差

Res istance Tolerance

D=±0.5%

F=±1%

G=± 2%

J=± 5%

101

公称抵抗値

Nominal Resistance

101:1 0×1 0

→100Ω

4 73:47×10

→

47kΩ

10R0→10.0Ω

4702:4 70× 10

→47kΩ

包装

Packing

V=テーピング

V=Taping

Dimension

Ｌ

0.60±0.03

1.00±0.05

1.60±0.15

2.00±0.20

3.20+0.05

-0.20

3.20±0.20

5.00±0.20

4.50±0.20

6.30±0.20

Inch

size

0201

0402

0603

0805

1206

1210

2010

1812

2512

Ｗ

0.30±0.03

0.50±0.05

0.80±0.15

1.25±0.10

1.60+0.05

-0.15

2.50+0.20

-0.10

2.50±0.15

3.20±0.20

0.23±0.03

0.35±0.05

0.45±0.10

0.50±0.10

0.13±0.05

0.20±0.10

0.30±0.20

0.40±0.20

0.50±0.25

0.15±0.05

0.25 +0.05

-0.10

0.30±0.20

0.40±0.20

0.50±0.20

0.50±0.30

0.50±0.20

0.70±0.20

包装数量

Q’ty

15,000pcs

10,000pcs

5,000pcs

Unit : mm

0.60±0.10

0.50±0.20

0.60±0.20

0.50±0.20

0.70

±0.20

4,000pcs
