3-520424-2 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> 3-520424-2

Preview

3-520424-2: DescriptionCONNECTOR, 6 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG; CategoryThe connector The connector; File Size129KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

3-520424-2 Overview

CONNECTOR, 6 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG

3-520424-2 Parametric

Parameter Name	Attribute value
Objectid	1504387154
Reach Compliance Code	unknown
Body/casing type	PLUG
Connector type	TELECOM AND DATACOM CONNECTOR
Contact to complete cooperation	GOLD (50) OVER NICKEL
Contact completed and terminated	GOLD FLASH (1) OVER NICKEL
Contact point gender	MALE
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
insulator material	COPPER ALLOY
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	520424
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	CABLE
Options	GENERAL PURPOSE
Shell material	POLYCARBONATE
Termination type	IDC
Total number of contacts	6
UL Flammability Code	94V-2

Preview

Download Datasheet

View All

3-520424-2 Related Products

	3-520424-2	6-520424-1	3-520424-1	3-520424-6	2-520424-1	2-520424-2	2-520424-3	4-520424-2	4-520424-3
Description	CONNECTOR, 6 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG	CONNECTOR, 4 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG	4 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG	CONNECTOR, 16 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG	CONNECTOR, 4 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG	CONNECTOR, 6 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG	CONNECTOR, 8 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG	CONNECTOR, 6 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG	CONNECTOR, 8 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, IDC, PLUG
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Body/casing type	PLUG	PLUG	PLUG	PLUG	PLUG	PLUG	PLUG	PLUG	PLUG
Connector type	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR
Contact to complete cooperation	GOLD (50) OVER NICKEL	GOLD (50) OVER NICKEL	GOLD (50) OVER NICKEL	GOLD (50) OVER NICKEL	GOLD (50) OVER NICKEL	GOLD (50) OVER NICKEL	GOLD (50) OVER NICKEL	GOLD (50) OVER NICKEL	GOLD (50) OVER NICKEL
Contact completed and terminated	GOLD FLASH (1) OVER NICKEL	GOLD FLASH (1) OVER NICKEL	GOLD FLASH (1) OVER NICKEL	GOLD FLASH (1) OVER NICKEL	GOLD FLASH (1) OVER NICKEL	GOLD FLASH (1) OVER NICKEL	GOLD FLASH (1) OVER NICKEL	GOLD FLASH (1) OVER NICKEL	GOLD FLASH (1) OVER NICKEL
Contact point gender	MALE	MALE	MALE	MALE	MALE	MALE	MALE	MALE	MALE
DIN compliance	NO	NO	NO	NO	NO	NO	NO	NO	NO
empty shell	NO	NO	NO	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO	NO	NO	NO
insulator material	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY
JESD-609 code	e4	e4	e4	e4	e4	e4	e4	e4	e4
MIL compliance	NO	NO	NO	NO	NO	NO	NO	NO	NO
Manufacturer's serial number	520424	520424	520424	520424	520424	520424	520424	520424	520424
Plug information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO	NO	NO	NO	NO	NO	NO	NO	NO
Installation type	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Shell material	POLYCARBONATE	POLYCARBONATE	POLYCARBONATE	POLYCARBONATE	POLYCARBONATE	POLYCARBONATE	POLYCARBONATE	POLYCARBONATE	POLYCARBONATE
Termination type	IDC	IDC	IDC	IDC	IDC	IDC	IDC	IDC	IDC
Total number of contacts	6	4	4	16	4	6	8	6	8
UL Flammability Code	94V-2	94V-2	94V-2	94V-2	94V-2	94V-2	94V-2	94V-2	94V-2
Objectid	1504387154	1504387328	1504387151	1504387160	1504387106	1504387109	1504387112	1504387190	-
Other features	-	-	EMI/RFI SHIELDED	-	EMI/RFI SHIELDED	EMI/RFI SHIELDED	EMI/RFI SHIELDED	EMI/RFI SHIELDED	EMI/RFI SHIELDED
