Tantalum Through-Hole Capacitors – Hermetically Sealed
T111 Series Axial MIL–PRF–39003 Non-Polar and
T213 (CSR91 Style)
Overview
The T111/T213 Series is primarily designed for use in tuned
low frequency circuits, phasing low voltage AC motors, servo
systems and other applications where reversal of polarity is a
primary consideration. The T111 unit consists of two polar T110
Series hermetically sealed tantalum capacitors, electrically and
mechanically connected back-to-back and supported by an
outer corrosion-resistant metal sleeve. They exhibit comparable
electrical and performance characteristics of T110 Series.
Available in capacitance values from 0.0023 µF to 160 µF in
±20% and ±10% tolerances, the T111 series is offered in working
voltages of 6 VDC to 100 VDC at +85°C.
Benefits
•
•
•
•
•
•
•
•
•
Taped and reeled per EIA Specification RS–296
Marking per MIL–STD–1285
Qualified to MIL–PRF–39003 (CSR91 Style)
Failure rate options: Graded - B, C, D, and G
Exponential - M, P, R, and S*
Capacitance values of 0.0023 μF to 160 μF
Tolerances of ±10% and ±20%
Voltage rating of 6 – 100 VDC
Operating temperature range of -55˚C to +125˚C
Case sizes: A, B, C, D
*Failure rates apply to military products only
Click image above for interactive 3D content
Open PDF in Adobe Reader for full functionality
Applications
Typical applications include use in tuned low frequency circuits, phasing low voltage AC motors, servo systems and other applications
where reversal of polarity is a primary consideration.
One world. One KEMET
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
T2032_T111_AXIAL_T213 • 11/19/2015
1
Tantalum Through-Hole Capacitors – Hermetically Sealed
T111 Series Axial MIL–PRF–39003 Non-Polar and T213 (CSR91 Style)
Ordering Information – T111
T
Capacitor
Class
T=
Tantalum
111
Series
Hermetically
Sealed Axial
capacitor
A
Case
Size
A, B,
C, D
105
Capacitance Code
(pF)
First two digits
represent significant
figures. Third digit
specifies number of
zeros.
K
K = ±10%
M = ±20%
050
006 = 6
010 = 10
015 = 15
020 = 20
035 = 35
050 = 50
075 = 75
100 = 100
A
A = N/A
S
Termination
Finish
S= Standard
(Sn/Pb)
Specification
All capacitors are sleeved
unless specified.
Capacitance Rated Voltage Failure Rate/Military
Tolerance
(VDC)
Product Only
Ordering Information – T213 (CSR91 Style)
MIL product
T
Capacitor
Class
T=
Tantalum
213
Series
A
Case
Size
115
Capacitance Code
(pF)
First two digits
represent significant
figures. Third digit
specifies number of
zeros.
K
K = ±10%
M = ±20%
020
006 = 6
010 = 10
015 = 15
020 = 20
035 = 35
050 = 50
075 = 75
100 = 100
B
Graded:
B = 0.1%/k hours
C = 0.01%/k hours
D = 0.001%/k hours
G= 1.0 %/k hours
Exponential:
M = 1%/k hours
P = 0.1%/k hours
R = 0.01%/k hours
S = 0.001%/k hours
S
Termination
Finish
S = Standard
(Sn/Pb)
7200
Specification
All capacitors are sleeved
unless specified.
0100 = Without sleeve
7200 = Tape & Reel
7293 & 7443 = Ammo
4250 = "A" surge current
4251 = "B" surge current
4252 = "C" surge current
Capacitance Rated Voltage Failure Rate/Military
Tolerance
(VDC)
Product Only
Hermetically A, B,
Sealed Axial C, D
Military grade
capacitor
Ordering Information – MIL–PRF–39003
M39003
Capacitor Class
Military
Specification
Number
/04
Slash
Specification
Sheet Number
3007
Dash Number
Failure Rate
Level
A
Surge Option
A = C-4250
B = C-4251
C = C-4252
Blank - No surge
Orders should be entered by the military specification number, including the dash number and surge option letter (A, B or C).
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
T2032_T111_AXIAL_T213 • 11/19/2015
2
Tantalum Through-Hole Capacitors – Hermetically Sealed
T111 Series Axial MIL–PRF–39003 Non-Polar and T213 (CSR91 Style)
Performance Characteristics
Item
Operating Temperature
Rated Capacitance Range
Capacitance Tolerance
Rated Voltage Range
DF (120 Hz at 25°C)
ESR and Impedance (100 kHz at 25°C)
Leakage Current
Failure Rate (MIL–39003, CSR91 capacitors only)
-55°C to 125°C
0.0023 μF–160 μF at 120 Hz/25°C
K Tolerance (10%), M Tolerance (20%)
6 – 100 V
Refer to Part Number Electrical Specification Table
Refer to Part Number Electrical Specification Table (for reference only)
Refer to Part Number Electrical Specification Table
(At rated voltage up to +85°C and 2/3 of rated voltage applied at 125°C)
Approved failure rate: S (0.001%/k hours) - Exponential, D (0.001%/k hours) - Graded
Performance Characteristics
Dimensions – Inches (Millimeters)
SIDE VIEW
1.50 ±0.250
(38.10 ±6.35)
END VIEW
1.50 ±0.250
(38.10 ±6.35)
C
D
B
L
Case
Size
A
B
C
D
Uninsulated
D
±0.005
(±0.13)
0.147
(3.73)
0.194
(4.93)
0.300
(7.62)
0.362
(9.19)
Insulated
D
±0.010
(±0.25)
0.161
(4.09)
0.207
(5.26)
0.314
(7.98)
0.376
(9.55)
L
±0.031
(±0.79)
0.565
(14.35)
0.916
(23.27)
1.340
(34.04)
1.540
(39.12)
L
±0.031
(±0.79)
0.575
(14.61)
0.955
(24.26)
1.350
(34.29)
1.550
(3.937)
B
±0.002
(±0.05)
0.020
(0.51)
0.020
(0.51)
0.025
(0.64)
0.025
(0.64)
C
Maximum
0.750
(19.05)
1.130
(28.70)
1.525
(38.74)
1.725
(43.82)
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
T2032_T111_AXIAL_T213 • 11/19/2015
3
Tantalum Through-Hole Capacitors – Hermetically Sealed
T111 Series Axial MIL–PRF–39003 Non-Polar and T213 (CSR91 Style)
Table 1 – Ratings & Part Number Reference
