DC DC
1 Watt
IF Series
•
•
•
•
•
•
•
Regulated Single Output
SIP or DIP Package
Low Ripple & Noise
1000 VDC Isolation
Optional 3000 VDC Isolation
MTBF 4.2 MHrs
3 Year Warranty
xppower.com
Specification
Input
Input Voltage Range
Input Reflected
Ripple Current
Input Reverse Voltage
Protection
• Nominal ±10%
• 20 mA pk-pk through 12 µH inductor,
5 Hz to 20 MHz
• None
Input Voltage
Output Voltage Output Current
3.3 V
5.0 V
5V
9.0 V
12.0 V
15.0 V
3.3 V
5.0 V
12 V
9.0 V
12.0 V
15.0 V
3.3 V
5.0 V
24 V
9.0 V
12.0 V
15.0 V
333 mA
200 mA
111 mA
84 mA
67 mA
333 mA
200 mA
111 mA
84 mA
67 mA
333 mA
200 mA
111 mA
84 mA
67 mA
Efficiency
57%
65%
65%
68%
68%
57%
63%
66%
68%
66%
60%
65%
68%
68%
68%
Model Number
(1,2)
IF0503S
IF0505S
IF0509S
IF0512S
IF0515S
IF1203S
IF1205S
IF1209S
IF1212S
IF1215S
IF2403S
IF2405S
IF2409S
IF2412S
IF2415S
Output
Output Voltage
Minimum Load
Line Regulation
Load Regulation
•
•
•
•
See table
None
(3)
±0.5% max
±0.5% max for a 10-100% load change
(3)
(±1.0% for 3.3 V output)
±2% max
50 mV pk-pk max, 20 MHz bandwidth
0.02%/°C
220 µF
Setpoint Accuracy
•
Ripple & Noise
•
Temperature Coefficient
•
Maximum Capacitive
•
Load
Mechanical Details
0.76
(19.50)
0.28
(7.20)
General
Efficiency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
MTBF
• See table
• 1000 VDC standard,
3000 VDC option
(2)
• 1000 MΩ min
• 60 pF typical
• 36-150 kHz variable
• 4.2 MHrs to MIL-HDBK-217F at 25 °C, GB
SIP
Package
0.37
(9.50)
0.39
(10.00)
0.02
(0.50)
0.08
(2.00)
0.12
(3.05)
0.01
(0.25)
0.10 (2.54)
0.60
(15.24)
1
2
4
5
6
7
0.28 (7.20)
0.02
(0.50)
Environmental
Operating Temperature
Storage Temperature
Case Temperature
Cooling
Notes
1. For DIP package, replace suffix ‘S’ with suffix ‘D’.
2. For 3000 VDC isolation, add suffix ‘-H’.
3. Operation at no load will not damage unit but it may not meet all specifications.
4. All dimensions in inches (mm).
5. Pin pitch tolerance: ±0.014 (±0.35)
6. Case tolerance: ±0.02 (±0.5)
7. Weight: 0.005 lbs (2.4 g)
1
Pin
1
2
4
5
6
7
Standard
+Vin
-Vin
-Vout
No Pin
+Vout
No Pin
‘-H’ Version
+Vin
-Vin
No Pin
-Vout
No Pin
+Vout
•
•
•
•
-40 °C to +85 °C (no derating)
-40 °C to +125 °C
+100 °C max
Convection-cooled
0.80
(20.32)
0.40
(10.16 )
0.12
(3.05)
DIP
Package
0.40
(10.16)
0.27 (6.85)
0.60
(15.24)
0.30
(7.62)
7
0.01
(0.25)
14
11
10
9
8
0.30
(7.62)
0.02
(0.50)
Pin
1
7
8
9
10
11
14
Standard
-Vin
N.C.
No Pin
+Vout
No Pin
-Vout
+Vin
‘-H’ Version
-Vin
N.C.
+Vout
No Pin
-Vout
No Pin
+Vin
21-Jan-11
