55A0813-20-6

Description
WIRE AND CABLE, FLEXIBLE CORD AND FIXTURE WIRE, 1 CONDUCTOR(S), 20AWG, 600V, ROHS COMPLIANT
CategoryThe connector    Connector bracket
File Size135KB，2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric Compare View All

55A0813-20-6 Overview

WIRE AND CABLE, FLEXIBLE CORD AND FIXTURE WIRE, 1 CONDUCTOR(S), 20AWG, 600V, ROHS COMPLIANT

55A0813-20-6 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTE Connectivity
package instructionROHS COMPLIANT
Reach Compliance Codeunknown
applicationAIRFRAME, MEDIUM WEIGHT
Conductor surface treatmentNICKEL
conductor materialCOPPER
Connector bracket typeWIRE AND CABLE
structureSTRANDED
Cross-sectional area0.62 mm2
diameter1.27 mm
Number of conductors1
Maximum operating temperature200 °C
Minimum operating temperature-65 °C
Rated voltage600 V
shieldNO
stay19X32
Wire gauge20 AWG
Wire and Cable NamesFLEXIBLE CORD AND FIXTURE WIRE
Base Number Matches1

Preview

Download Datasheet
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Wire & Cable > Product Feature Selector > Product Details
55A0813­20­6 Product Details
Spec 44, Spec 55 and Spec RCW Wire and Cable

Always EU RoHS/ELV Compliant
 (
Statement of Compliance
)
Product Highlights:
Cable Type = Spec 55
Wire Source = United States
Cable Style = Primary
Wire Size (AWG/CM) = 20 AWG
Voltage Rating = 600 VAC
View all Features
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
55A0813­20­6

TE Internal Number: 218343­003
 Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
WIRE, RADIATION­CROSSLINKED, MODIFIED ETFE­INSULATED... (PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Cable Type = Spec 55
Cable Style = Primary
Electrical Characteristics:
Voltage Rating (VAC) = 600
Dimensions:
Conductor Outer Diameter (mm [in]) = 1.01 [0.040]
Body Features:
Wire Size (AWG/CM) = 20 AWG
Conductor Type = Nickel­Plated Copper
Wire Color = Blue
Nominal Outside Diameter (mm [in]) = 1.27 [0.050]
Wire Diameter (mm [in]) = 1.27 [0.050]
Configuration Features:
Number of Conductors = 1
Industry Standards:
Government/Industry Qualification = No
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
Temperature Range (°C) = ­65 – +200
Wire Size ­ Details = 20 AWG 0.62 mm², 0.00095 in², 19 x 32 AWG
Operation/Application:
Application = Airframe ­ Medium Weight
Packaging Features:
Wire Source = United States
Other:
Brand = Raychem
Corporate Information
About TE
Investors
News Room
Supplier Portal
Careers
Terms & Conditions
Quick Links
Distributor Inventory
Product Cross Reference
Documents & Drawings
Product Compliance Support Center
Site Map
Customer Support
Email or Chat With Us
Find a Phone Number
Knowledge Base
Manage Your Account
Keep Me Informed


55A0813-20-6 Related Products

55A0813-20-6 218343-003
Description WIRE AND CABLE, FLEXIBLE CORD AND FIXTURE WIRE, 1 CONDUCTOR(S), 20AWG, 600V, ROHS COMPLIANT WIRE AND CABLE, FLEXIBLE CORD AND FIXTURE WIRE, 1 CONDUCTOR(S), 20AWG, 600V, ROHS COMPLIANT
Is it Rohs certified? conform to conform to
package instruction ROHS COMPLIANT ROHS COMPLIANT
Reach Compliance Code unknown compliant
application AIRFRAME, MEDIUM WEIGHT AIRFRAME, MEDIUM WEIGHT
Conductor surface treatment NICKEL NICKEL
conductor material COPPER COPPER
Connector bracket type WIRE AND CABLE WIRE AND CABLE
structure STRANDED STRANDED
Cross-sectional area 0.62 mm2 0.62 mm2
diameter 1.27 mm 1.27 mm
Number of conductors 1 1
Maximum operating temperature 200 °C 200 °C
Minimum operating temperature -65 °C -65 °C
Rated voltage 600 V 600 V
shield NO NO
stay 19X32 19X32
Wire gauge 20 AWG 20 AWG
Wire and Cable Names FLEXIBLE CORD AND FIXTURE WIRE FLEXIBLE CORD AND FIXTURE WIRE
