560KD10JY datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 560KD10JY

560KD10JY: DescriptionRESISTOR, VOLTAGE DEPENDENT, 45V, 8.1J, THROUGH HOLE MOUNT, RADIAL LEADED; CategoryPassive components The resistor; File Size118KB，6 Pages; ManufacturerMicro Commercial Components (MCC)

Download Datasheet Parametric View All

560KD10JY Overview

RESISTOR, VOLTAGE DEPENDENT, 45V, 8.1J, THROUGH HOLE MOUNT, RADIAL LEADED

560KD10JY Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	1715998007
package instruction	RADIAL LEADED
Reach Compliance Code	compliant
ECCN code	EAR99
YTEOL	0
Circuit RMS maximum voltage	35 V
Maximum energy absorption capacity	8.1 J
JESD-609 code	e0
Installation features	THROUGH HOLE MOUNT
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Package shape	DISK PACKAGE
method of packing	BULK; TR
Rated power dissipation(P)	0.05 W
Rated temperature	85 °C
Resistor type	VARISTOR
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Terminal location	RADIAL
Terminal shape	WIRE
Operating Voltage	45 V

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla Street Chatsworth

!"#

$ % !"#

182KD10JX*

thru

180LD10JX*

11 to 1000 Volts

Varistor

2.6 to 247Joule

Features

•

High Surge, High Energy

Designed to be Operated Continuously Across AC Power Lines

No Derating Up to 85 Ambient

Available in Tape and Reel or Bulk Pack

UL Recognized File # E306895(UL1449) and E306942(UL1414)

Maximum Ratings

•

Operating Ambient Temperature Range: -55 to +85

Storage Temperature Range: -55 to +125

Temperature Coefficient ( V) of Clamping Voltage (V

) at

Specified Test Current:<0.05%/

Varistor voltage temperature coefficient:

Vb at 25 - Vb at 85

Vb at 25

x(100/

)

Kink Lead

120

100

L: 20mm Min.

DIMENSIONS

Unit: mm

Size D max

H max

C/I/Y

19.5

D±

0.05

All

0.6

0.8

E±

1.0

All

7.5

Lead

05D

07D

-55

100

120

140

160

All

7.5

12.5

16.5

10D

14D

AMBIENT TEMPERATURE (°C)

PERCENT OF RATED VALUE

CURRENT, ENERGY AND POWER DERATING

CURVE

Note :

'X' can be S, C, I or Y .

'S'

'C'

'I'

'Y'

denotes

straight lead

out crimped lead

inner crimped lead

kink lead

20D

www.mccsemi.com

Revision: 2

1 of 6

2006/09/09
