DC-DC Converters
TDR2SM Series, 2 Watt
Features
•
•
•
•
•
•
•
•
Compact design in SMD package
Wide 2:1 input range
Fully regulated outputs
No minimum load requirement
I/O isolation 1500VDC
Operating temperature range -40°C to +85°C
Short circuit protection
Remote ON/OFF
Electrical Specification
Short Circuit Protection
Operating Temperature Range
I/O Isolation test voltage
Safety Approvals
Casing
Remote ON/OFF
continuous, automatic recovery
-40°C to +85°C (without derating)
1500VDC
cUL/UL 60950-1, IEC/EN 60950-1
epoxy moulded (UL94V-0 rated)
shutdown input for low current (2.5mA) in standby operation
www.powersolve.co.uk
Output Voltage and Current Ratings
MODEL
TDR2-0511SM
TDR2-0512SM
TDR2-0513SM
TDR2-0522SM
TDR2-0523SM
TDR2-1211SM
TDR2-1212SM
TDR2-1213SM
TDR2-1222SM
TDR2-1223SM
TDR2-2411SM
TDR2-2412SM
TDR2-2413SM
TDR2-2422SM
TDR2-2423SM
TDR2-4811SM
TDR2-4812SM
TDR2-4813SM
TDR2-4822SM
TDR2-4823SM
INPUT
VOLTAGE
OUTPUT
VOLTAGE
5VDC
12VDC
15VDC
±12VDC
±15VDC
5VDC
12VDC
15VDC
±12VDC
±15VDC
5VDC
12VDC
15VDC
±12VDC
±15VDC
5VDC
12VDC
15VDC
±12VDC
±15VDC
OUTPUT
CURRENT
400mA
167mA
134mA
±83mA
±67mA
400mA
167mA
134mA
±83mA
±67mA
400mA
167mA
134mA
±83mA
±67mA
400mA
167mA
134mA
±83mA
±67mA
RIPPLE &
NOISE
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
30mV pk-pk max.
LINE
REG.
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
0.2%
LOAD
REG.
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
EFF.
(typ.)
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
81%
4.5 - 9VDC
9 - 18VDC
18 - 36VDC
36 - 75VDC
Mechanical and Connection Details
Dimensions in mm (inches)
Pin
1
2
6
7
8
9
14
Single Output
-Vin (GND)
Remote ON/OFF
No Conn.
No Conn.
+Vout
-Vout
+Vin (Vcc)
Dual Output
-Vin (GND)
Remote ON/OFF
Common
-Vout
+Vout
Common
+Vin (Vcc)
