536366-4 Product Details
Live Product Chat
Product Photo
Eurocard Type C
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
536366-4
T E I nternal N umber: 5 3 6 3 6 6 - 4
Product Highlights:
l
Type C C onnectors
l
Plug
l
Number of Positions = 96
l
Rows Loaded = A, B, C
l
Terminate To Printed C ircuit Board
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Type C C onnectors
l
Gender
= Plug
l
Number of Positions
= 96
l
PC B Retention Feature
= Yes
l
PC B Mount Angle
= Right Angle
l
PC B Thickness (Minimum) (mm [in])
= 1.57 [0.062]
l
Post Type
= Solder Post
l
Size
= Standard
l
Make First / Break Last
= Yes
l
Bus Type
= FUTUREBUS, MULTIBUS (II), NUBUS, VMEbus, VXIBus
l
DIN Level
= II
l
Mounting Ears
= Without
l
Toolless (Flat Rock) = No
l
C omment = C ontact Finish: DIN 41612 C lass 2 In C ontact Area.
Tin-Lead On Posts.
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.65 [0.104]
Body Related Features:
l
Rows Loaded
= A, B, C
l
PC B Retention Method
= Boardlock(s)
l
C ontact C ross Section (mm [in])
= 0.64 [.025] Sq.
l
Make First/Break Last C ontacts Loaded
= Row A - 1, 3-30, 32, Rows
B, C - 3-30
Contact Related Features:
l
C ontact Base Material = Brass
Housing Related Features:
l
Housing Material = Polyester GF
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
l
Flux-Tight C oating
= Without
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
l
High Temperature Housing
= No
Other:
l
Brand = AMP
